2025

Merida eONE-EIGHTY 500

Name: 2025 Merida eONE-EIGHTY 500
Brand: Merida

E-Mountain Enduro

Compare

Size / X-Short, Short, Mid, Long, X-Long

Manufacturer Website

At a glance

The 2025 Merida eONE-EIGHTY 500 is a E-Mountain and Enduro Aluminium / Alloy mountain bike. It is priced at £5,750 GBP, comes in a range of sizes, including X-Short, Short, Mid, Long, X-Long, has RockShox suspension and a Shimano drivetrain. The bike is part of Merida's eONE-EIGHTY range of mountain bikes. As a pedal-assisted e-mountain bike, the Merida eONE-EIGHTY 500 is powered by a Bosch Performance Line CX motor and a Bosch PowerTube 800 Wh, removeable battery.

Where To Buy

Merida

Merida eONE-EIGHTY 500

Loading more...

Reviews

Specifications

Frameset

Frame

eONE-EIGHTY LITE, material: aluminium, 180mm suspension travel, 27.5"" x 2.6" max. wheelsize, 148x12mm axle standard
Fork

Rock Shox Zeb Base eMTB, Air, 180mm suspension travel, Tapered, 44mm fork offset, 29x2.6"" max wheelsize
Shock

Rockshox Zeb Base eMTB, Air, 180 STR, Tapered, 44mm fork offset, 29x2.6"" max WHS
Motor

Bosch Performance Line CX
Battery

Bosch PowerTube 800 Wh, removeable

Wheels

Hubs

Shimano TC500, 15x100mm width front hub, 32 spoke holes, Centerlock, 12x148mm width rear hub, 32 spoke holes, Centerlock
Wheels

MERIDA EXPERT TR II, 110x15mm width front hub, 148x12mm width rear hub, 28mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included), front 29"", rear 27.5"
Spokes

Black stainless
Tires

Front: Maxxis Assegai, 29x2.5 "", fold, TR EXO+ 3C MaxxGrip
Rear: Maxxis Minion DHR II, 27.5x2.4 ", fold, 3C DD TR MaxxTerra

Drivetrain

Chain

Shimano LG500
Crank

FSA 1x Alloy Spider + Mega Tooth steel chain ring, 36 teeth
Bottom Bracket

BSA, threaded
Rear Derailleur

Shimano CUES U6000, GS
Shifters

Shimano SL -MT500-L / Shimano Cues U6000-10

Components

Brakeset

Tektro Gemini M535, 4 piston
Handlebar

MERIDA EXPERT eTR, 780mm width, XS,S 20RHB, M,L,XL 30RHB
Saddle

MERIDA COMP SL, 28% recycled material, V-mount
Seatpost

MERIDA EXPERT TR II, 34.9mm diameter, 0mm setback, XS: 125mm travel seatpost - S: 150mm travel seatpost - M/L: 200mm travel seatpost - XL: 230mm travel seatpost
Stem

MERIDA EXPERT eTR II, material: aluminium, 35mm diameter, 0° stem angle, Supernova mount, 40 mm all sizes
Headset

Acros ICR MERIDA EXTERNAL neck w/ Blocklock

Have some feedback or spotted an issue? Let us know.

Geometry

Frame Size	X				X
Bottom Bracket Drop	12mm	12mm	12mm	12mm	12mm
Chainstay Length	435mm	435mm	435mm	435mm	435mm
Front Center	760mm	783mm	810mm	837mm	859mm
Head Tube Angle	64.5°	64.5°	64.5°	64.5°	64.5°
Head Tube Length	110mm	115mm	120mm	125mm	130mm
Rake	36mm	37mm	37mm	36mm	36mm
Reach	415mm	435mm	460mm	485mm	505mm
Seat Tube Angle	78.5°	78.5°	78.5°	78.5°	78.5°
Seat Tube Length	400mm	410mm	425mm	445mm	465mm
Stack	652mm	657mm	661mm	666mm	670mm
Stack Reach Ratio	1.571	1.51	1.437	1.373	1.327
Top Tube Length	556mm	577mm	604mm	630mm	652mm
Trail	139mm	138mm	138mm	139mm	139mm
Wheel Kind Front	29	29	29	29	29
Wheel Kind Rear	27.5	27.5	27.5	27.5	27.5
Wheelbase	1195mm	1218mm	1245mm	1272mm	1294mm

Have some feedback or spotted an issue? Let us know.

FAQ

Q: How much is a 2025 Merida eONE-EIGHTY 500?

A 2025 Merida eONE-EIGHTY 500 is typically priced around £5,750 GBP when new. Be sure to shop around for the best price, and also look to the used market for a great deal.

Q: Where to buy a 2025 Merida eONE-EIGHTY 500?

The 2025 Merida eONE-EIGHTY 500 may be purchased directly from Merida.

Q: What size 2025 Merida eONE-EIGHTY 500 should I get?

The 2025 Merida eONE-EIGHTY 500 comes in sizes X-Short, Short, Mid, Long, X-Long. After measuring your height, use the size chart below to find the typical Merida eONE-EIGHTY 500 size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm)	Rider Height (in)	Frame Size
148cm - 158cm	4'10" - 5'2"	XS
158cm - 168cm	5'2" - 5'6"	S
168cm - 178cm	5'6" - 5' 10"	M
178cm - 185cm	5'10" - 6'1"	L
185cm - 193cm	6'1" - 6'4"	XL
193cm - 198cm	6'4" - 6'6"	XXL
