Image of Trek Marlin 6
2022

Trek Marlin 6

Trek Marlin 2022

779

Cross Country

Size / 13.5", 15.5", 17.5", 18.5", 19.5", 21.5", 23"

Weight / 14.11

Manufacturer Website

At a glance

The 2022 Trek Marlin 6 is an Cross Country Aluminium / Alloy mountain bike. It sports 29" and 27.5" wheels, is priced at $779 USD, comes in a range of sizes, including 13.5", 15.5", 17.5", 18.5", 19.5", 21.5", 23", has SR Suntour suspension and a Shimano drivetrain. The bike is part of Trek's Marlin range of mountain bikes.

Where To Buy

Trek Logo
Trek
Trek Marlin 6
Loading more...

Reviews

Specifications

Frameset
  • Frame
    Alpha Silver Aluminum, internal routing, chainstay disc brake mount, rack and kickstand mount, 135x5mm QR
  • Fork
    SunTour XCT, Size: XS, SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42mm offset for 27.5'' wheel, 100mm QR, 80mm travel; Size: S, SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42mm offset for 27.5'' wheel, 100mm QR, 100mm travel; Size: M, ML, L, XL, XXL, SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 46mm offset for 29'' wheel, 100mm QR, 100mm travel
Wheels
  • Hubs
    Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR
  • Wheels
    Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve
  • Wheel Size
    29" 27.5"
  • Spokes
    14g stainless steel
  • Tires
    Size: XS, S, Bontrager XR2 Comp, wire bead, 30 tpi, 27.5x2.20''; Size: M, ML, L, XL, XXL, Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.20''
Drivetrain
  • Chain
    KMC, KMC X10, 10 speed
  • Crank
    Prowheel C10Y-NW, 30T steel narrow-wide ring, 170mm length
  • Bottom Bracket
    VP BC73, 73mm, threaded cartridge
  • Rear Derailleur
    Shimano Deore, Shimano Deore M5120, long cage
  • Shifters
    Shimano Deore, Shimano Deore M4100, 10 speed
Components
  • Brakeset
    Tektro, Size: XS, S, Tektro HD-M276 hydraulic disc, short reach lever; Size: M, ML, L, XL, XXL, Tektro HD-M275 hydraulic disc
  • Handlebar
    Size: XS, Bontrager alloy, 31.8mm, 5mm rise, 690mm width; Size: S, M, ML, L, XL, XXL, Bontrager alloy, 31.8mm, 5mm rise, 720mm width
  • Saddle
    Bontrager Arvada, steel rails, 138mm width
  • Seatpost
    Size: XS, S, M, Bontrager alloy, 31.6mm, 12mm offset, 330mm length; Size: ML, L, XL, XXL, Bontrager alloy, 31.6mm, 12mm offset, 400mm length
  • Stem
    Size: XS, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 50mm length; Size: S, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 60mm length; Size: M, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 70mm length; Size: ML, L, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 80mm length; Size: XL, XXL, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 90mm length
  • Grips
    Bontrager XR Endurance Comp, lock-on
  • Headset
    Semi-integrated, 1-1/8''

FAQ

Q: How much is a 2022 Trek Marlin 6?

A 2022 Trek Marlin 6 is typically priced around $779 USD when new. Be sure to shop around for the best price, and also look to the used market for a great deal.

Q: Where to buy a 2022 Trek Marlin 6?

The 2022 Trek Marlin 6 may be purchased directly from Trek.

Q: How much does a 2022 Trek Marlin 6 weigh?

A 2022 Trek Marlin 6 weights 14.11.

Q: What size wheels does the 2022 Trek Marlin 6 have?

The 2022 Trek Marlin 6 has 29" and 27.5" wheels.

Q: What size 2022 Trek Marlin 6 should I get?

The 2022 Trek Marlin 6 comes in sizes 13.5", 15.5", 17.5", 18.5", 19.5", 21.5", 23". After measuring your height, use the below size chart to find the correct size Trek Marlin 6 for your height.

Rider Height (cm)Rider Height (in)Frame Size
148cm - 158cm4'10" - 5'2"XS
158cm - 168cm5'2" - 5'6"S
168cm - 178cm5'6" - 5' 10"M
178cm - 185cm5'10" - 6'1"L
185cm - 193cm6'1" - 6'4"XL
193cm - 198cm6'4" - 6'6"XXL
