Image of Trek Marlin 7
2022

Trek Marlin 7

Trek Marlin 2022

949

Cross Country

Size / 13.5", 15.5", 17.5", 18.5", 19.5", 21.5", 23"

Weight / 13.47

Manufacturer Website

At a glance

The 2022 Trek Marlin 7 is an Cross Country Aluminium / Alloy mountain bike. It sports 29" and 27.5" wheels, is priced at $949 USD, comes in a range of sizes, including 13.5", 15.5", 17.5", 18.5", 19.5", 21.5", 23", has RockShox suspension and a Shimano drivetrain. The bike is part of Trek's Marlin range of mountain bikes.

Where To Buy

Trek Logo
Trek
Trek Marlin 7
Loading more...

Reviews

Specifications

Frameset
  • Frame
    Alpha Silver Aluminum, internal routing, chainstay disc brake mount, rack and kickstand mount, 135x5mm QR
  • Fork
    RockShox Judy, Size: XS, RockShox Judy, coil spring, preload, TurnKey lockout, 42mm offset for 27.5'' wheel, 100mm QR, 80mm travel; Size: S, RockShox Judy, coil spring, preload, TurnKey lockout, 42mm offset for 27.5'' wheel, 100mm QR, 100mm travel; Size: M, ML, L, XL, XXL, RockShox Judy, coil spring, preload, TurnKey lockout, 46mm offset for 29'' wheel, 100mm QR, 100mm travel
Wheels
  • Hubs
    Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR
  • Wheels
    Bontrager Kovee, double-wall, Tubeless Ready, 32-hole, 23mm width, presta valve
  • Wheel Size
    29" 27.5"
  • Spokes
    14g stainless steel
  • Tires
    Size: XS, S, Bontrager XR2 Comp, wire bead, 30 tpi, 27.5x2.20''; Size: M, ML, L, XL, XXL, Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.20''
Drivetrain
  • Chain
    KMC, KMC X10, 10 speed
  • Crank
    FSA, Size: XS, S, M, FSA Alpha Drive, 28T steel ring, Boost, 170mm length; Size: ML, L, XL, XXL, FSA Alpha Drive, 28T steel ring, Boost, 175mm length
  • Bottom Bracket
    FSA, 73mm, threaded cartridge, 122.5mm spindle
  • Rear Derailleur
    Shimano Deore, Shimano Deore M5120, long cage
  • Shifters
    Shimano Deore, Shimano Deore M4100, 10 speed
Components
  • Brakeset
    Shimano, Shimano MT200 hydraulic disc
  • Handlebar
    Size: XS, Bontrager alloy, 31.8mm, 5mm rise, 690mm width; Size: S, M, ML, L, XL, XXL, Bontrager alloy, 31.8mm, 5mm rise, 720mm width
  • Saddle
    Bontrager Arvada, steel rails, 138mm width
  • Seatpost
    Size: XS, S, M, Bontrager alloy, 31.6mm, 12mm offset, 330mm length; Size: ML, L, XL, XXL, Bontrager alloy, 31.6mm, 12mm offset, 400mm length
  • Stem
    Size: XS, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 50mm length; Size: S, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 60mm length; Size: M, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 70mm length; Size: ML, L, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 80mm length; Size: XL, XXL, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 90mm length
  • Grips
    Bontrager XR Trail Comp, nylon lock-on
  • Headset
    Semi-integrated, 1-1/8''

FAQ

Q: How much is a 2022 Trek Marlin 7?

A 2022 Trek Marlin 7 is typically priced around $949 USD when new. Be sure to shop around for the best price, and also look to the used market for a great deal.

Q: Where to buy a 2022 Trek Marlin 7?

The 2022 Trek Marlin 7 may be purchased directly from Trek.

Q: How much does a 2022 Trek Marlin 7 weigh?

A 2022 Trek Marlin 7 weights 13.47.

Q: What size wheels does the 2022 Trek Marlin 7 have?

The 2022 Trek Marlin 7 has 29" and 27.5" wheels.

Q: What size 2022 Trek Marlin 7 should I get?

The 2022 Trek Marlin 7 comes in sizes 13.5", 15.5", 17.5", 18.5", 19.5", 21.5", 23". After measuring your height, use the size chart below to find the typical Trek Marlin 7 size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm) Rider Height (in) Frame Size
148cm - 158cm 4'10" - 5'2" XS
158cm - 168cm 5'2" - 5'6" S
168cm - 178cm 5'6" - 5' 10" M
178cm - 185cm 5'10" - 6'1" L
185cm - 193cm 6'1" - 6'4" XL
193cm - 198cm 6'4" - 6'6" XXL
