2025

Amflow PL Carbon Pro (600Wh/800Wh)

Name: 2025 Amflow PL Carbon Pro (600Wh/800Wh)
Brand: Amflow

E-Mountain Enduro

Compare

Size / MD, LG, XL, XXL

Manufacturer Website

At a glance

The 2025 Amflow PL Carbon Pro (600Wh/800Wh) is a E-Mountain and Enduro Carbon mountain bike. It comes in a range of sizes, including MD, LG, XL, XXL and has Fox suspension. The bike is part of Amflow's PL range of mountain bikes. As a pedal-assisted e-mountain bike, the Amflow PL Carbon Pro (600Wh/800Wh) is powered by a Avinox M1 Drive Unit: 105 N·m, Avinox Screen: 2-inch OLED Control Display, Avinox Integrated Battery: 600Wh/800Wh, Avinox Wireless Controllers: Right and left sides, Avinox Fast Charger: 12A/508W motor and a Avinox M1 Drive Unit: 105 N·m, Avinox Screen: 2-inch OLED Control Display, Avinox Integrated Battery: 600Wh/800Wh, Avinox Wireless Controllers: Right and left sides, Avinox Fast Charger: 12A/508W battery.

Where To Buy

Amflow

Amflow PL Carbon Pro (600Wh/800Wh)

Loading more...

Reviews

Specifications

Frameset

Frame

Amflow PL Carbon Frame, Cosmic Black, 150mm rear travel, Compatible with 27.5"" and 29" rear wheels
Fork

FOX 36 Factory, 160mm travel, GRIP X2 Damper, 15×110mm, 44mm rake
Shock

FOX FLOAT X Factory, Trunnion (185×55mm), custom tune, EVOL Air sleeve, 2-position lever w/ LSC adjustment
Motor

Avinox M1 Drive Unit: 105 N·m, Avinox Screen: 2-inch OLED Control Display, Avinox Integrated Battery: 600Wh/800Wh, Avinox Wireless Controllers: Right and left sides, Avinox Fast Charger: 12A/508W
Battery

Avinox M1 Drive Unit: 105 N·m, Avinox Screen: 2-inch OLED Control Display, Avinox Integrated Battery: 600Wh/800Wh, Avinox Wireless Controllers: Right and left sides, Avinox Fast Charger: 12A/508W

Wheels

Wheels

Amflow HMC-30, Rims: Carbon, 29'', 30mm internal width, 28H, tubeless ready, Spokes: SAPIM E-Light Straightpull, Front Hub: Alloy, 2 sealed cartridge bearings, 15×110mm thru-axle, 28h, straight-pull, 6-bolt, Rear Hub: Alloy, 4 sealed cartridge bearings, 148×12mm thru-axle, 28h, straight-pull, 6-bolt, 78T
Tires

Front: Maxxis Assegai MaxxTerra 29×2.5"" WT 3C EXO E-25 TLR
Rear: Maxxis Dissector MaxxTerra 29×2.4" WT 3C EXO+ E-25 TLR

Drivetrain

Components

Brakeset

Magura MT7 Pro hydraulic disc brake, HC lever, 4-piston caliper, 203mm Storm HC Rotor (front and rear)
Handlebar

Amflow Enduro Carbon Handlebar, 25mm rise, 800mm wide, 5-degree upsweep, 9-degree backsweep
Saddle

Ergon SM PRO M/L
Seatpost

Fox Transfer Factory, Travel adjustable in 5mm, M: 125-150mm, L/XL: 155-180mm, XXL: 185-210mm
Stem

Amflow Enduro Stem, One-piece CNC, Length: 35mm, Clamping diameter: 35mm
Grips

Amflow Enduro Grips

Have some feedback or spotted an issue? Let us know.

Geometry

Frame Size	MD	LG	XL	XXL
Bottom Bracket Drop	29mm	29mm	29mm	29mm
Bottom Bracket Height	345.5mm	345.5mm	345.5mm	345.5mm
Chainstay Length	445mm	445mm	445mm	445mm
Front Center	782mm	810mm	844mm	873mm
Head Tube Angle	64.5°	64.5°	64.5°	64.5°
Head Tube Length	105mm	115mm	130mm	145mm
Rake	45mm	45mm	48mm	45mm
Reach	452mm	475mm	500mm	525mm
Seat Tube Angle	77°	77°	77°	77°
Seat Tube Length	430mm	450mm	470mm	500mm
Stack	618mm	628mm	641mm	655mm
Stack Reach Ratio	1.367	1.322	1.282	1.248
Standover Height	780mm	785mm	790mm	795mm
Top Tube Length	595mm	620mm	648mm	676mm
Trail	129mm	129mm	125mm	129mm
Wheel Kind Front	29	29	29	29
Wheel Kind Rear	29	29	29	29
Wheelbase	1227mm	1255mm	1289mm	1318mm

Have some feedback or spotted an issue? Let us know.

FAQ

Q: Where to buy a 2025 Amflow PL Carbon Pro (600Wh/800Wh)?

The 2025 Amflow PL Carbon Pro (600Wh/800Wh) may be purchased directly from Amflow.

Q: What size 2025 Amflow PL Carbon Pro (600Wh/800Wh) should I get?

The 2025 Amflow PL Carbon Pro (600Wh/800Wh) comes in sizes MD, LG, XL, XXL. After measuring your height, use the size chart below to find the typical Amflow PL Carbon Pro (600Wh/800Wh) size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm)	Rider Height (in)	Frame Size
148cm - 158cm	4'10" - 5'2"	XS
158cm - 168cm	5'2" - 5'6"	S
168cm - 178cm	5'6" - 5' 10"	M
178cm - 185cm	5'10" - 6'1"	L
185cm - 193cm	6'1" - 6'4"	XL
193cm - 198cm	6'4" - 6'6"	XXL
