2024

Giant Trance X Advanced E+ Elite 3

Name: 2024 Giant Trance X Advanced E+ Elite 3
Brand: Giant

E-Mountain Trail

Compare

Size / SM High, SM Low, MD High, MD Low, LG High, LG Low, XL High, XL Low

Manufacturer Website

At a glance

The 2024 Giant Trance X Advanced E+ Elite 3 is a E-Mountain and Trail mountain bike. It comes in a range of sizes, including SM High, SM Low, MD High, MD Low, LG High, LG Low, XL High, XL Low, has Marzocchi suspension and a Shimano drivetrain. The bike is part of Giant's Trance range of mountain bikes. As a pedal-assisted e-mountain bike, the Giant Trance X Advanced E+ Elite 3 is powered by a Giant SyncDrive Pro2 Mg, 85Nm, PedalPlus 6-Sensor technology motor and a Giant EnergyPak 400Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 200 range extender compatible battery.

Where To Buy

Giant

Giant Trance X Advanced E+ Elite 3

Loading more...

Reviews

Specifications

Frameset

Frame

Advanced-grade composite frame, Aluxx SL-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system
Fork

Marzocchi Bomber Z2 E-Tuned, 29er, 150mm travel, 44mm offset, RAIL damper Sweep-Adj, Kabolt 110
Shock

Fox Float Performance, EVOL Large Volume sleeve, 2pos, 185x52.5mm Trunnion mount, custom tuned, recommended sag: 30%
Motor

Giant SyncDrive Pro2 Mg, 85Nm, PedalPlus 6-Sensor technology
Battery

Giant EnergyPak 400Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 200 range extender compatible

Wheels

Hubs

Shimano MT410 Boost, Center-Lock, 110x15 [F] 148x12 Shimano Micro-Spline Drive Body Thru-axle [R]
Wheels

Giant AM30, Tubeless ready, 30mm inner width, 29"" [F] / 27.5" [R]
Spokes

Sapim E-Lite [R] Race [F], e-bike optimized
Tires

Maxxis Minion DHF 29X2.50"" Foldable, TLR, EXO [F]Maxxis Dissector 27.5x2.4" Foldable, TLR, EXO [R]

Drivetrain

Chain

KMC e.12 Turbo, EcoProteq, e-bike optimized
Crank

Praxis N.W. 36T Cold Forged 4130 premium steel Praxis e-Cranks (Q-factor=168, S:160, M/L:165, XL:170)
Front Derailleur

MRP HD2 co-moulded chain guide
Rear Derailleur

Shimano Deore 12-speed, Shadow+
Shifters

Shimano Deore

Components

Brakeset

Shimano BR-MT420, 4-piston, hydraulic disc,203mm [F/R]
Handlebar

Giant Contact SL 35 Trail, 35x780mm
Saddle

Giant Romero
Seatpost

Tranz-X Rad+ 30,9mm, 30mm travel adjustable (S:120-150mm, M:140-170mm, L/XL:170-200mm)
Stem

Giant Contact SL 35
Grips

Giant Tactal Pro-E, tapered design, 135mm Ø28~30mm (S/M) 142mm Ø29~32mm (L/XL)

Have some feedback or spotted an issue? Let us know.

Geometry

Frame Size	SM	SM	MD	MD	LG	LG	XL	XL
Bottom Bracket Drop	10mm	10mm	10mm	10mm	10mm	10mm	10mm	10mm
Bottom Bracket Height	345mm	345mm	345mm	345mm	345mm	345mm	345mm	345mm
Chainstay Length	447mm	447mm	447mm	447mm	447mm	447mm	447mm	447mm
Crank Length	160mm	160mm	165mm	165mm	165mm	165mm	170mm	170mm
Front Center	748mm	747mm	765mm	768mm	797mm	797mm	828mm	828mm
Handlebar Width	780mm	780mm	780mm	780mm	780mm	780mm	780mm	780mm
Head Tube Angle	66.5°	65.7°	66.5°	65.8°	66.5°	65.8°	66.5°	65.8°
Head Tube Length	95mm	95mm	100mm	100mm	115mm	115mm	130mm	130mm
Rake	44mm	44mm	44mm	44mm	44mm	44mm	44mm	44mm
Reach	447mm	439mm	462mm	457mm	487mm	480mm	513mm	505mm
Seat Tube Angle	78°	77.2°	76.7°	76°	76.7°	76°	76.7°	76°
Seat Tube Length	400mm	400mm	425mm	425mm	450mm	450mm	475mm	475mm
Stack	601mm	607mm	605mm	611mm	619mm	625mm	633mm	639mm
Stack Reach Ratio	1.345	1.383	1.31	1.337	1.271	1.302	1.234	1.265
Standover Height	735mm	726mm	742mm	733mm	741mm	732mm	750mm	741mm
Stem Length	40mm	40mm	40mm	40mm	50mm	50mm	50mm	50mm
Top Tube Length	575mm	577mm	605mm	607mm	634mm	636mm	663mm	665mm
Trail	108mm	113.1mm	108mm	113.1mm	108mm	113.1mm	108mm	113.1mm
Wheel Kind Front	27.5	27.5	27.5	27.5	27.5	27.5	27.5	27.5
Wheel Kind Rear	27.5	27.5	27.5	27.5	27.5	27.5	27.5	27.5
Wheelbase	1195mm	1194mm	1212mm	1215mm	1244mm	1244mm	1275mm	1275mm

Have some feedback or spotted an issue? Let us know.

FAQ

Q: Where to buy a 2024 Giant Trance X Advanced E+ Elite 3?

The 2024 Giant Trance X Advanced E+ Elite 3 may be purchased directly from Giant.

Q: What size 2024 Giant Trance X Advanced E+ Elite 3 should I get?

The 2024 Giant Trance X Advanced E+ Elite 3 comes in sizes SM High, SM Low, MD High, MD Low, LG High, LG Low, XL High, XL Low. After measuring your height, use the size chart below to find the typical Giant Trance X Advanced E+ Elite 3 size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm)	Rider Height (in)	Frame Size
148cm - 158cm	4'10" - 5'2"	XS
158cm - 168cm	5'2" - 5'6"	S
168cm - 178cm	5'6" - 5' 10"	M
178cm - 185cm	5'10" - 6'1"	L
185cm - 193cm	6'1" - 6'4"	XL
193cm - 198cm	6'4" - 6'6"	XXL
