2024

Rossignol E-Track Fat E-Bike

Name: 2024 Rossignol E-Track Fat E-Bike
Brand: Rossignol

E-Mountain Fat Bike

Compare

Size / MD, LG, XL

Manufacturer Website

At a glance

The 2024 Rossignol E-Track Fat E-Bike is a E-Mountain and Fat Bike mountain bike. It is priced at £3,739 GBP, comes in a range of sizes, including MD, LG, XL and a Shimano drivetrain. The bike is part of Rossignol's e track range of mountain bikes. As a pedal-assisted e-mountain bike, the Rossignol E-Track Fat E-Bike is powered by a Shimano STEPS MTB EP601; 85nm; 25km/h motor and a Shimano BT8036 or BT8035-L batteries are fully integrated into the bike frame. Offering 503Wh or 630Wh capacity enables you to ride enough distance for all-day adventures. Take a break and quickly recharge up to 50% capacity in only 2.5hrs. Battery can be easily removed from the frame with a 4mm Allen key. battery.

Where To Buy

Rossignol

Rossignol E-Track Fat E-Bike

Loading more...

Reviews

Specifications

Frameset

Frame

Rossignol Hardtail Fat Electric
Fork

RST Renegade 100mm
Motor

Shimano STEPS MTB EP601; 85nm; 25km/h
Battery

Shimano BT8036 or BT8035-L batteries are fully integrated into the bike frame. Offering 503Wh or 630Wh capacity enables you to ride enough distance for all-day adventures. Take a break and quickly recharge up to 50% capacity in only 2.5hrs. Battery can be easily removed from the frame with a 4mm Allen key.

Wheels

Wheels

Alex DP30-F & Shimano hubs
Tires

MAXXIS 26x4.8 Minion F

Drivetrain

Chain

Shimano LG500
Crank

Samox ET39-F30, 34T
Rear Derailleur

Shimano CUES, SGS 10-SPEED
Shifters

Shimano Cues SL-U6000, 10speed

Components

Brakeset

Shimano MT-410, 2-piston
Handlebar

ROSSIGNOL MTB handlebar 780mm
Saddle

VELO MTB SADDLE
Seatpost

Kalloy 30.9
Stem

ROSSIGNOL MTB stem 31,8mm
Grips

Rossignol diamond grip lock-on
Headset

FSA 1-1/8'' - 1,5''

Have some feedback or spotted an issue? Let us know.

Geometry

Frame Size	MD	LG	XL
Bottom Bracket Drop	25mm	25mm	25mm
Bottom Bracket Height	349mm	349mm	349mm
Chainstay Length	450mm	450mm	450mm
Front Center	753mm	765mm	791mm
Head Tube Angle	65°	65°	65°
Head Tube Length	100mm	110mm	120mm
Rake	47mm	43mm	46mm
Reach	439mm	455mm	475mm
Seat Tube Angle	78°	78°	78°
Seat Tube Length	375mm	425mm	445mm
Stack	613mm	617mm	626mm
Stack Reach Ratio	1.396	1.356	1.318
Top Tube Length	572mm	585mm	610mm
Trail	123mm	127mm	124mm
Wheel Kind Front	29	29	29
Wheel Kind Rear	29	29	29
Wheelbase	1214mm	1228mm	1255mm

Have some feedback or spotted an issue? Let us know.

FAQ

Q: How much is a 2024 Rossignol E-Track Fat E-Bike?

A 2024 Rossignol E-Track Fat E-Bike is typically priced around £3,739 GBP when new. Be sure to shop around for the best price, and also look to the used market for a great deal.

Q: Where to buy a 2024 Rossignol E-Track Fat E-Bike?

The 2024 Rossignol E-Track Fat E-Bike may be purchased directly from Rossignol.

Q: What size 2024 Rossignol E-Track Fat E-Bike should I get?

The 2024 Rossignol E-Track Fat E-Bike comes in sizes MD, LG, XL. After measuring your height, use the size chart below to find the typical Rossignol E-Track Fat E-Bike size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm)	Rider Height (in)	Frame Size
148cm - 158cm	4'10" - 5'2"	XS
158cm - 168cm	5'2" - 5'6"	S
168cm - 178cm	5'6" - 5' 10"	M
178cm - 185cm	5'10" - 6'1"	L
185cm - 193cm	6'1" - 6'4"	XL
193cm - 198cm	6'4" - 6'6"	XXL
