KTM MACINA AERA 772 LFC
KTM MACINA AERA 2023 E-Mountain Cross CountrySize / XS, SM, MD, LG, XL
Manufacturer WebsiteAt a glance
The 2023 KTM MACINA AERA 772 LFC is a E-Mountain and Cross Country Aluminium / Alloy mountain bike. It sports 27.5" wheels, comes in a range of sizes, including XS, SM, MD, LG, XL, has SR Suntour suspension and a Shimano drivetrain. The bike is part of KTM's MACINA AERA range of mountain bikes. As a pedal-assisted e-mountain bike, the KTM MACINA AERA 772 LFC is powered by a Bosch PERFORMANCE CX Gen.4 SMART SYSTEM - 25km/h / 85Nm motor and a Bosch PowerTUBE 750Wh SMART SYSTEM hor. battery.Where To Buy
KTM
KTM MACINA AERA 772 LFCReviews
Specifications
Frameset
-
FrameMacina Trekking Onroad Alloy6061; PT750Wh Bosch Gen.4 / T-2940
-
ForkSuntour XCR 34 Air 27.5"" LOR 80mm 15x110 taper
-
MotorBosch PERFORMANCE CX Gen.4 SMART SYSTEM - 25km/h / 85Nm
-
BatteryBosch PowerTUBE 750Wh SMART SYSTEM hor.
Wheels
-
WheelsKTM Line - Shimano MT410B CL 32H 110-15TA / Ryde Rival30 32H 584x30C / DT Champion 2.0 black
-
Wheel Size27.5"
Drivetrain
-
ChainShimano LG500
-
CrankKTM E-COMP ISIS 170mm Q16
-
Bottom BracketBosch, press-fit
-
Rear DerailleurShimano Deore M5130-10 LG shadow+
-
ShiftersShimano Deore M5130-10 LG display
Components
-
BrakesetTektro HD-M535 4-Piston
-
HandlebarKTM COMP II rizer15 680mm
-
SaddleSelle Royal Lookin+
-
SeatpostKTM Team 30.9/300
-
StemKTM adjust. 0-60° ICR
-
HeadsetAcros AICR internal 1.1/8""-1.5" angle limit
FAQ
Q: Where to buy a 2023 KTM MACINA AERA 772 LFC?
The 2023 KTM MACINA AERA 772 LFC may be purchased directly from KTM.
Q: What size wheels does the 2023 KTM MACINA AERA 772 LFC have?
The 2023 KTM MACINA AERA 772 LFC has 27.5" wheels.
Q: What size 2023 KTM MACINA AERA 772 LFC should I get?
The 2023 KTM MACINA AERA 772 LFC comes in sizes XS, SM, MD, LG, XL. After measuring your height, use the size chart below to find the typical KTM MACINA AERA 772 LFC size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.
| Rider Height (cm) | Rider Height (in) | Frame Size |
|---|---|---|
| 148cm - 158cm | 4'10" - 5'2" | XS |
| 158cm - 168cm | 5'2" - 5'6" | S |
| 168cm - 178cm | 5'6" - 5' 10" | M |
| 178cm - 185cm | 5'10" - 6'1" | L |
| 185cm - 193cm | 6'1" - 6'4" | XL |
| 193cm - 198cm | 6'4" - 6'6" | XXL |
