Trek Fuel EX 7

Frameset

• Frame

  Alpha Platinum Aluminum, tapered head tube, Knock Block, Control Freak internal routing, downtube guard, ISCG 05, magnesium rocker link, Mino Link, ABP, Boost148, 130mm travel
• Fork

  RockShox 35 Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 44mm offset, Boost110, 15mm Maxle Stealth, 140mm travel
• Shock

  Size: XS , S Fox Performance Float EVOL, 3-position DPS damper, tuned by Trek Suspension Lab, 210x52.5mm
  Size: S , M , ML , L , XL , XXL Fox Performance Float EVOL, 3-position DPS damper, tuned by Trek Suspension Lab, 210x55mm

Wheels

• Wheel Size

  27.5"
• Tires

  Size: XS , S Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 27.5x2.40''
  Size: XS , S Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 27.5x2.60''

Drivetrain

• Chain

  SRAM NX Eagle, 12 speed
• Crank

  Size: XS , S SRAM NX Eagle, DUB, 30T steel ring, Boost (52mm chainline), 170mm length
  Size: M , ML , L , XL , XXL SRAM NX Eagle, DUB, 30T steel ring, Boost (52mm chainline), 175mm length
• Shifters

  SRAM NX Eagle, 12 speed
• Cassette

  SRAM PG-1230 Eagle, 11-50, 12 speed

Components

• Brakeset

  Shimano hydraulic disc, MT4100 lever, MT410 caliper
• Handlebar

  Bontrager alloy, 31.8mm, 15mm rise, 750mm width
• Saddle

  Bontrager Arvada, steel rails, 138mm width
• Seatpost

  Size: XS , S TranzX JD-YSP18, 100mm travel, internal routing, 31.6mm, 361mm length
  Size: M , ML , L , XL , XXL TranzX JD-YSP18, 150mm travel, internal routing, 31.6mm, 445mm length
• Headset

  Knock Block Integrated, 58-degree radius, cartridge bearing, 1-1/8'' top, 1.5'' bottom
