Rocky Mountain Element Carbon 90

Frameset

• Frame

  Smoothwall carbon front and rear triangles; molded chainstay, seatstay, and down tube protection
• Fork

  FOX FLOAT 34 Step-Cast (SC) Factory, 51mm offset, 120mm
• Shock

  FOX FLOAT DPS Factory, size-specific tune, 6.5" x 1.5"

Wheels

• Hubs

  Front: Rocky Mountain, sealed bearings, 110x15mm Boost
  Rear: DT Swiss 350, 148x12mm Boost, 36 tooth Ratchet, MICRO SPLINE driver
• Wheels

  Race Face ARC 25, tubeless ready (tape and valves included), 32 hole
• Wheel Size

  29"
• Spokes

  DT Swiss Competition, 1.8/1.6/1.8 double-butted
• Tires

  Front: Maxxis Rekon, 3C MaxxTerra, EXO, TR, 29" x 2.4"
  Rear: Maxxis Ikon, 3C MaxxSpeed, EXO, TR, 29" x 2.35"

Drivetrain

• Chain

  439mm, 437mm, None, Race Face Next SL G5 Cinch, 32 tooth, Shimano XTR, 12-speed
• Crank

  Race Face Next SL G5 Cinch, 30mm spindle, 170mm length
• Bottom Bracket

  44mm drop, 31mm drop, 45mm drop, 31mm drop, Race Face BB92, 92mm press-fit
• Rear Derailleur

  Shimano XTR, 12-speed
• Shifters

  Shimano XTR, 12-speed

Components

• Brakeset

  Shimano XTR, 2-piston, metal pads, Shimano RT86 rotors (180mm front, 160mm rear), Shimano XTR
• Handlebar

  Race Face Next, 760mm width, 8° backsweep, 4° upsweep, 35mm clamp diameter, 10mm rise
• Saddle

  WTB Silverado Team, titanium rails, 142mm width
• Seatpost

  FOX Transfer Factory dropper, 30.9mm, Standard single bolt, 30.9mm, Standard single bolt
  Drop:
  125mm (SM)
  150mm (MD/LG)
  175mm (XL/XXL)
• Stem

  Rocky Mountain 35 CNC, 0° rise, 35mm bar clamp, Length: 60mm (SM/MD), 80mm (LG/XL/XXL)
• Grips

  Ergon GD1 EVO, lock-on
• Headset

  FSA Orbit No.57E
