Trek Remedy 9.7

Frameset

• Frame

  OCLV Mountain Carbon main frame & stays, tapered head tube, Knock Block, Control Freak internal routing, Carbon Armor, ISCG 05, magnesium rocker link, Mino Link, ABP, Boost148, 150mm travel
• Fork

  RockShox Lyrik Select+, DebonAir spring, Charger 2 RC damper, tapered steerer, 46mm offset, Boost110, 15mm Maxle Stealth, 160mm travel
• Shock

  RockShox Deluxe RT3, RE:aktiv 3-position damper, tuned by Trek Suspension Lab, 230x57.5 mm

Wheels

• Wheel Size

  27.5"
• Tires

  Size: S, M, M/L, L, XL Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 27.5x2.60''
  Size: S, M, M/L, L, XL Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 27.5x2.60''

Drivetrain

• Chain

  SRAM NX Eagle, 12 speed
• Crank

  Size: S Truvativ Descendant 6k Eagle, DUB, 32T steel ring, Boost, 170mm length
  Size: M, M/L, L, XL Truvativ Descendant 6k Eagle, DUB, 32T steel ring, Boost, 175mm length
• Bottom Bracket

  SRAM DUB, 92mm, PressFit
• Rear Derailleur

  SRAM GX Eagle
• Shifters

  SRAM NX Eagle, 12 speed

Components

• Brakeset

  SRAM Guide R hydraulic disc, 200mm front rotor, 180mm rear rotor
• Saddle

  Bontrager Arvada, hollow chromoly rails, 138mm width
• Seatpost

  Size: S Bontrager Line Dropper, 100mm travel, internal routing, 31.6mm, 345mm length
  Size: M, M/L, L, XL Bontrager Line Dropper, 150mm travel, internal routing, 31.6mm, 440mm length
• Headset

  Knock Block Integrated, cartridge bearing, 1-1/8'' top, 1.5'' bottom
