Trek Fuel EX 9.9 X01 AXS
Trek Fuel-Ex 20208999.99
TrailWeight / M - 12.97 kg / 28.60 lbs (with TLR sealant no tubes)
Manufacturer WebsiteAt a glance
The 2020 Trek Fuel EX 9.9 X01 AXS is an Trail Carbon mountain bike. It sports 29" and 27.5" wheels, is priced at $9,000 USD, has Fox suspension and a SRAM drivetrain. The bike is part of Trek's Fuel-Ex range of mountain bikes.Fuel EX 9.9 is light, fast, and decked out with top-shelf components. It has a carbon frame, carbon wheels, FOX Factory Float suspension, and a fully wireless SRAM X01 Eagle AXS electronic drivetrain and RockShox Reverb AXS dropper. This is the one carbon full suspension mountain bike that rules every trail—it’s fast on singletrack, light on climbs, and stable through the rowdiest terrain you can find.
Where To Buy
Trek
Trek Fuel EX 9.9 X01 AXSReviews
"A world-class trail bike"
"Fuel EX is a beautifully balanced and capable trail bike. The rear suspension is beautiful; as close to ideal as any bike I've ridden. It's sensitive where you want it to be, firm and crisp where it should be. It feels deep and controls big hits very well, and there's a nice platform for pedaling, and to pump and pop off when you're playing."
"Good at pleasing everybody"
"Fuel EX has a few tricks that help it keep a level head when outside of its comfort zone, and to be a cloud on rails when it's in the zone. Everything about the Fuel EX, which was already good at pleasing everybody, is now even better at it."
"An absolute trail rocket"
"Thanks to its burlier components, increased travel, and more aggressive geometry, it has become more of a shredder than ever! More performance, fun, and trail prowess."
Specifications
Frameset
-
FrameOCLV Mountain Carbon main frame & stays, internal storage, tapered head tube, Knock Block, Control Freak internal routing, Carbon Armor, ISCG 05, magnesium rocker link, Mino Link, ABP, Boost148, 130mm travel
-
ForkFox Factory 36, Float EVOL air spring, GRIP2 damper, tapered steerer, 44mm offset, Kashima Coat, Boost110, 15mm bolt-on axle, 140mm travel
-
ShockSize: XS , S Fox Factory Float EVOL, RE:aktiv with Thru Shaft 3-position damper, Kashima Coat, tuned by Trek Suspension Lab, 210x52.5mm
Size: S , M , ML , L , XL Fox Factory Float EVOL, RE:aktiv with Thru Shaft 3-position damper, Kashima Coat, tuned by Trek Suspension Lab, 210x55mm
Wheels
-
WheelsFront: Bontrager Line Carbon 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle
Rear: Bontrager Line Carbon 30, Tubeless Ready, 54T Rapid Drive, 6-bolt, SRAM XD driver, Boost148, 12mm thru axle -
Wheel Size29" 27.5"
-
TiresSize: XS , S Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 27.5x2.60''
Size: S , M , ML , L , XL Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 29x2.60''
Drivetrain
-
ChainSRAM XX1 Eagle, 12 speed
-
CrankSize: XS , S SRAM X01 Eagle AXS Carbon, DUB, 32T alloy ring, Boost, 170mm length
Size: M , ML , L , XL SRAM X01 Eagle AXS Carbon, DUB, 32T alloy ring, Boost, 175mm length -
Bottom BracketSRAM DUB, 92mm, PressFit
-
Rear DerailleurSRAM X01 Eagle AXS
-
ShiftersSRAM Eagle AXS, wireless, 12-speed
Components
-
BrakesetShimano XT M8120 4-piston hydraulic disc
-
HandlebarBontrager Line Pro, OCLV Carbon, 35mm, 27.5mm rise, 780mm width
-
SaddleBontrager Arvada, austenite rails, 138mm width
-
SeatpostSize: XS , S RockShox Reverb AXS, 100mm travel, wireless, 31.6mm, 340mm length
Size: M , ML RockShox Reverb AXS, 150mm travel, wireless, 31.6mm, 440mm length -
StemSize: XS , S
Size: M , ML , L , XL -
HeadsetKnock Block Integrated, cartridge bearing, 1-1/8'' top, 1.5'' bottom
FAQ
Q: How much is a 2020 Trek Fuel EX 9.9 X01 AXS?
A 2020 Trek Fuel EX 9.9 X01 AXS is typically priced around $9,000 USD when new. Be sure to shop around for the best price, and also look to the used market for a great deal.
Q: Where to buy a 2020 Trek Fuel EX 9.9 X01 AXS?
The 2020 Trek Fuel EX 9.9 X01 AXS may be purchased directly from Trek.
Q: How much does a 2020 Trek Fuel EX 9.9 X01 AXS weigh?
A 2020 Trek Fuel EX 9.9 X01 AXS weights M - 12.97 kg / 28.60 lbs (with TLR sealant no tubes).
Q: What size wheels does the 2020 Trek Fuel EX 9.9 X01 AXS have?
The 2020 Trek Fuel EX 9.9 X01 AXS has 29" and 27.5" wheels.
Q: What size 2020 Trek Fuel EX 9.9 X01 AXS should I get?
After measuring your height, use the size chart below to find the typical Trek Fuel EX 9.9 X01 AXS size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.
| Rider Height (cm) | Rider Height (in) | Frame Size |
|---|---|---|
| 148cm - 158cm | 4'10" - 5'2" | XS |
| 158cm - 168cm | 5'2" - 5'6" | S |
| 168cm - 178cm | 5'6" - 5' 10" | M |
| 178cm - 185cm | 5'10" - 6'1" | L |
| 185cm - 193cm | 6'1" - 6'4" | XL |
| 193cm - 198cm | 6'4" - 6'6" | XXL |
