Image of Giant Fathom E+ 1 Pro
2019

Giant Fathom E+ 1 Pro

Giant Fathom E+ Pro 2019

E-Mountain

Colour / Neon Yellow

Size / XS, S, M, L, XL

At a glance

The 2019 Giant Fathom E+ 1 Pro is an E-Mountain mountain bike. It sports 27.5" wheels, comes in a range of sizes, including XS, S, M, L, XL, has RockShox suspension and a Shimano drivetrain. The bike is part of Giant's Fathom E+ Pro range of mountain bikes.

- Ride rough roads, paths or singletrack with power and control. This new off-road E-bike helps you conquer hills and challenging terrain in a whole new way. The all-new Fathom E+ is built on a lightweight ALUXX SL aluminum frame with trail-friendly geometry. It has a 500Wh EnergyPak that’s integrated into the downtube and the RideControl ONE handlebar control buttons. Smooth looks and even smoother performance.

Designed to ride on a variety of terrain, from mild XC to more challenging technical trails, it delivers responsive hardtail handling. The SyncDrive Pro motor technology gives you 360 percent tunable power, and you can adjust it exactly the way you want. The frame is designed for and fitted with a 120mm suspension fork, and the Giant E-bike App connects you with health, fitness and navigation functions.

Where To Buy

Reviews

Specifications

Frameset
  • Frame
    ALUXX SL aluminum, Overdrive 1½ - 1⅛" head tube, 148x12mm Thru-Axle, integrated KS18 kickstand mount
  • Fork
    Rock Shox Revelation RL 120mm travel, Tapered 1½ - 1⅛" steerer,110x15QR, lockout
Wheels
  • Hubs
    Giant eTracker Boost, Sealed cartridge bearing, 6-bolt, Front: 110x15
    Rear: 148x12mm Thru-axle, e-bike optimized
  • Wheels
    Giant AM 27.5+, Tubeless ready, 35mm inner width, e-bike optimized
  • Wheel Size
    27.5"
  • Spokes
    Sapim E-Lite [r] Race [f], e-bike optimized
  • Tires
    Maxxis Forekaster 27.5x2.6, foldable, 60 TPI, EXO, Tubeless Ready
Drivetrain
  • Chain
    KMC e.11 Turbo, EcoProteq, e-bike optimized
  • Crank
    Praxis Wavetm 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set
  • Rear Derailleur
    Shimano Deore XT, 11-Speed, Shadow+
  • Shifters
    Shimano SLX
  • Cassette
    Shimano HG-M7000, 11-46T, 11-Speed
Components
  • Brakeset
    Shimano BR-MT500, hydraulic disc, 180/200mm
  • Handlebar
    Giant Connect TR, 31,8x780mm
  • Saddle
    Giant Contact, Neutral
  • Seatpost
    Giant Contact Switch, dropper, 30,9mm, under bar remote lever
  • Stem
    Giant Connect

FAQ

Q: What size wheels does the 2019 Giant Fathom E+ 1 Pro have?

The 2019 Giant Fathom E+ 1 Pro has 27.5" wheels.

Q: What size 2019 Giant Fathom E+ 1 Pro should I get?

The 2019 Giant Fathom E+ 1 Pro comes in sizes XS, S, M, L, XL. After measuring your height, use the size chart below to find the typical Giant Fathom E+ 1 Pro size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm) Rider Height (in) Frame Size
148cm - 158cm 4'10" - 5'2" XS
158cm - 168cm 5'2" - 5'6" S
168cm - 178cm 5'6" - 5' 10" M
178cm - 185cm 5'10" - 6'1" L
185cm - 193cm 6'1" - 6'4" XL
193cm - 198cm 6'4" - 6'6" XXL
