Image of Specialized Pitch Expert 650b
2016

Specialized Pitch Expert 650b

Specialized Pitch 2016

Street

At a glance

The 2016 Specialized Pitch Expert 650b is an Street Aluminium / Alloy mountain bike. It has SR Suntour suspension and a Shimano drivetrain. The bike is part of Specialized's Pitch range of mountain bikes.

When it comes to mountain bike efficiency, it’s hard to beat a hardtail. And when it comes to learning the ropes of mountain biking, efficiency is the name of the game. With this in mind, our Pitch Expert 650b features a hardtail design that keeps the rear end of the bike planted to the trail under effort, while our acclaimed Sport Trail 650b Geometry ensures that you’ll feel comfortable and confident in the process. And to keep with this theme, it features a lightweight aluminium frame that adds to compliance on the downhill and speed when you’re going up the trail. Sprinkle in a thoughtful component selection and plenty of suspension up front to get the job done, and you have yourself a bike that’s ready to hit the dirt.

Where To Buy

Reviews

Specifications

Frameset
  • Frame
    Specialized A1 Premium Aluminium, Sport Trail 650b Geometry, butted tube sets, externally relieved head tube, forged dropouts, reinforced disc mount, replaceable alloy derailleur hanger
  • Fork
    Custom SR Suntour XCR-AIR 650b, custom Multi-Circuit Damping, air spring, S: 80mm travel, M/L/XL: 100mm travel, integrated remote hydraulic lockout, rebound adjust, preload adjust, tapered alloy steerer, mag lowers, Hi-Ten 32mm stanchions, disc mount
Wheels
  • Hubs
    [F] Specialized Stout XC, Hi Lo disc, alloy, RCC bearing system, QR, 28h [R] Specialized Stout XC, Hi Lo disc, alloy, RCC bearing system, QR, 32h
  • Wheels
    Specialized Stout XC 650b, disc, alloy, double-wall, pin joint, 26mm inner width, 32h
  • Spokes
    Stainless, 14g, black
  • Tires
    [F] [R]
Drivetrain
  • Chain
    KMC X10, 10-speed, w/ reusable MissingLink
  • Crank
    Specialized Stout XC, 2-piece 2x10, 24mm spindle, anti-corrosion hardware
  • Bottom Bracket
    Samox, 24mm BSA for 2 pc. design, 73mm
  • Front Derailleur
    SRAM X5, 2x10, high mount
  • Rear Derailleur
    Shimano Deore Shadow, 10-speed
  • Shifters
    Shimano Deore, RapidFire Plus, 10-speed
  • Cassette
    Sunrace, 10-speed, 11-36t
  • Pedals
    Alloy platform
Components
  • Brakeset
    [F] Tektro Gemini, hydraulic disc, resin pads, i-Spec compatible, 180mm rotor [R] Tektro Gemini, hydraulic disc, resin pads, I-spec compatible, 160mm rotor
  • Handlebar
    Specialized Stout, double-butted 6061 alloy, 9-degree backsweep, 5-degree upsweep, 15mm rise, 31.8mm
  • Saddle
    Body Geometry mountain, steel rails, 143mm
  • Seatpost
    Alloy, 2-bolt, micro-adjust, 12.5mm offset, 30.9mm, anti-corrosion hardware
  • Stem
    Specialized Stout, 3D forged alloy, 4-bolt, 6-degree rise, anti-corrosion hardware

FAQ

Q: What size 2016 Specialized Pitch Expert 650b should I get?

After measuring your height, use the size chart below to find the typical Specialized Pitch Expert 650b size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm)Rider Height (in)Frame Size
148cm - 158cm4'10" - 5'2"XS
158cm - 168cm5'2" - 5'6"S
168cm - 178cm5'6" - 5' 10"M
178cm - 185cm5'10" - 6'1"L
185cm - 193cm6'1" - 6'4"XL
193cm - 198cm6'4" - 6'6"XXL
