At a glance
The 2016 Specialized Fuse Pro 6Fattie is an Cross Country mountain bike. It has RockShox suspension and a SRAM drivetrain. The bike is part of Specialized's Fuse range of mountain bikes.The Fuse Pro 6Fattie is the next step in the evolution of trail riding. Now we know that sounds bold coming from a hardtail, but with our all-new 6Fattie Wheel System, the Fuse puts out more traction, more floatation, and better handling, all without sacrificing anything to efficiency. And when teamed-up with a low and slack geometry that keeps you glued to the trail, and our exclusive Diamond Stay design that keeps the chainstays as short as possible for snappy handling and quick accelerations, that bold statement above becomes undeniable fact.
Where To Buy
Specialized
Specialized Fuse Pro 6FattieReviews
Specifications
Frameset
-
FrameSpecialized M4 Premium Aluminum, Trail 6Fattie Geometry, fully-butted w/ smooth welds, tapered head tube, tapered seat tube, forged 160mm disc mounts, 148mm thru-axle dropouts, replaceable alloy derailleur hanger
-
ForkRockShox Reba RC3 650+, Solo Air spring, S: 100mm travel, M/L/XL: 120mm travel, compression adjust, rebound adjust, lockout, tapered alloy steerer, forged hollow aluminum crown, Maxle stealth, disc mount
Wheels
-
HubsFront: Specialized, Hi Lo disc, alloy, cartridge bearings, 15x110mm thru-axle, QR, 24h
Rear: Specialized disc, alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h -
WheelsRoval 650b, alloy, 38mm wide, 2Bliss Ready, 24/28h
-
SpokesDT Swiss Industry, stainless
-
TiresFront: Specialized 6Fattie Ground Control, 60TPI, 2Bliss Ready, folding bead, 650bx3.0""
Rear: Specialized 6Fattie Ground Control, 60TPI, 2Bliss Ready, folding bead, 650bx3.0""
Drivetrain
-
ChainKMC X11L, 11-speed, w/ reusable MissingLink
-
CrankSRAM S-2200, carbon, 148-specific chain line, PF30, X-Sync 30T direct mount ring
-
Bottom BracketSRAM PF30, OS press-in bearings
-
Rear DerailleurSRAM X01 Type 2.1, 11-speed, carbon cage
-
ShiftersSRAM X1, 11-speed, trigger
-
CassetteSRAM XG-1175, 11-speed, 10-42t
-
PedalsAlloy platform
Components
-
BrakesetFront: SRAM DB5 Trail, 4-piston, semi-metallic pads, 180mm rotor
Rear: SRAM DB5, dual piston, semi-metallic pads, 160mm rotor -
HandlebarSpecialized Mini-rise, 7050 alloy, 8-backsweep, 6-upsweep, 10mm rise, 720mm width, 31.8mm clamp
-
SaddleBody Geometry Henge Comp, thin padding, hollow Cr-Mo rails, 143mm
-
SeatpostCommand Post IRcc, cruiser control technology, micro-adjust height adjustable, alien head design, bottom mount cable routing, remote adjust SRL lever, 30.9mm, S: 100mm travel, M/L/XL: 125mm travel
-
StemSpecialized Trail, 3D forged alloy, 4-bolt, 6-degree rise
FAQ
Q: What size 2016 Specialized Fuse Pro 6Fattie should I get?
After measuring your height, use the size chart below to find the typical Specialized Fuse Pro 6Fattie size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.
| Rider Height (cm) | Rider Height (in) | Frame Size |
|---|---|---|
| 148cm - 158cm | 4'10" - 5'2" | XS |
| 158cm - 168cm | 5'2" - 5'6" | S |
| 168cm - 178cm | 5'6" - 5' 10" | M |
| 178cm - 185cm | 5'10" - 6'1" | L |
| 185cm - 193cm | 6'1" - 6'4" | XL |
| 193cm - 198cm | 6'4" - 6'6" | XXL |
