Image of Specialized Fatboy Expert
2014

Specialized Fatboy Expert

Specialized Fatboy 2014

Fat Bike

At a glance

The 2014 Specialized Fatboy Expert is an Fat Bike mountain bike. It sports 26" wheels and a SRAM drivetrain. The bike is part of Specialized's Fatboy range of mountain bikes.

All the fun of a fat bike with the performance of a Specialized. The Fatboy combines a lightweight frame and fork with 4.6 Specialized Ground Control tyres for nimble handling in the most extreme conditions.

Where To Buy

Reviews

Specifications

Frameset
  • Frame
    New Specialized M4 Premium Aluminum, Fat Bike Geometry, fully butted w/ smooth welds, tapered headtube, post-mount disc dropouts, replaceable alloy derailleur hanger
  • Fork
    FACT carbon full monocoque, 5.0"" tire clearance, 135mm spacing
Wheels
  • Hubs
    [F] Specialized MTB disc, alloy, Hi Lo flange, sealed bearings, 135mm wide, alloy axle, QR, 32h [R] Specialized MTB disc, alloy, Hi Lo flange, sealed bearings, 190mm wide, alloy axle, QR, 32h
  • Wheels
    Specialized Fatboy SL, alloy disc, single wall, 90mm wide, sleeve joint, hookless design, 32 hole
  • Wheel Size
    26"
  • Spokes
    Stainless, double butted, threadlock, 14g
  • Tires
    [F] Specialized Ground Control, 26x4.6"", aramid bead, 120TPI [R] Specialized Ground Control, 26x4.6"", aramid bead, 120TPI
Drivetrain
  • Chain
    KMC X-10L, hollow outer links
  • Crank
    Custom e.thirteen, 2 piece, PF30, 100mm spindle, 170mm/175mm length
  • Bottom Bracket
    e.thirteen PF30, included w/ crankset
  • Front Derailleur
    SRAM X7, low direct mount
  • Rear Derailleur
    SRAM X0, Type 2, 10-speed
  • Shifters
    SRAM S-Series, Grip Shift twist shifter, 10-speed
  • Cassette
    Sunrace, 10-speed, , alloy spacers, alloy lock-ring, 11-36
  • Pedals
    Specialized Bennies, 6061 alloy body, sealed cartridge bearings, removal 4.5mm pins
Components
  • Brakeset
    [F] Shimano Deore, BR-505, hydraulic disc, 180mm rotor [R] Shimano Deore, BR-505, hydraulic disc, 160mm rotor
  • Handlebar
    Specialized mini riser bar, 6061 double-butted alloy, 660/700mm wide, 10-degree backsweep, 6-degree upsweep, 31.8mm
  • Saddle
    Body Geometry Henge SL, hollow Cr-Mo rails, lite PU foam, 143mm
  • Seatpost
    Specialized alloy, 2-bolt, micro-adjust, 30.9mm, 350mm/400mm
  • Stem
    Specialized 3D forged 6061 alloy, 4-bolt clamp, 6-degree rise, 60mm/70mm length, 31.8mm

FAQ

Q: What size wheels does the 2014 Specialized Fatboy Expert have?

The 2014 Specialized Fatboy Expert has 26" wheels.

Q: What size 2014 Specialized Fatboy Expert should I get?

After measuring your height, use the size chart below to find the typical Specialized Fatboy Expert size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm)Rider Height (in)Frame Size
148cm - 158cm4'10" - 5'2"XS
158cm - 168cm5'2" - 5'6"S
168cm - 178cm5'6" - 5' 10"M
178cm - 185cm5'10" - 6'1"L
185cm - 193cm6'1" - 6'4"XL
193cm - 198cm6'4" - 6'6"XXL
