2019

Orbea Occam TR H20 Plus

Name: 2019 Orbea Occam TR H20 Plus
Brand: Orbea

Trail

Compare

Colour / Black, Orange/Black

Size / S - 29", M - 29", L - 29", XL - 29"

Manufacturer Website

At a glance

The 2019 Orbea Occam TR H20 Plus is an Trail Aluminium / Alloy mountain bike. It sports 27.5" wheels, is priced at $3,299 USD, comes in a range of sizes, including S - 29", M - 29", L - 29", XL - 29", has Fox suspension and a SRAM drivetrain. The bike is part of Orbea's Occam TR range of mountain bikes.

Rubber chainstay protector and downtube protector

Where To Buy

Orbea

Orbea Occam TR H20 Plus

Loading more...

Reviews

Specifications

Frameset

Frame

Hydro, triple butted alloy, internal cable routing
Fork

FOX 34 Float Performance, 3-position, QR15x110, 51mm offset, Upgrade option: FOX 34 Float Factory, Kashima, FIT4, 3-pos adjust, QR15x110, 130mm
Shock

FOX Float DPS Performance EVOL, 3-position, custom tune, 184mm x 44mm, Upgrade option: FOX Float DPS Factory EVOL, Kashima, 3-pos adjust, 184mm x 44mm

Wheels

Hubs

SUNringlé Duroc 40 wheelset, Upgrade option: FOX Kabolt Boost front axle, DT Swiss RWS Alloy rear through axle, 12x148mm
Wheels

SUNringlé Duroc 40 wheelset, tubeless ready
Wheel Size

27.5"
Spokes

SUNringlé Duroc 40 wheelset
Tires

Front: Maxxis High Roller II 3.00" TLR, 60 tpi, EXO
Rear: Maxxis Rekon 2.8" TLR, 60 tpi, EXO

Drivetrain

Chain

435, None included, Upgrade option: OneUp Components ISCG05 guide, 32 tooth, SRAM NX Eagle, 12-speed
Crank

SRAM Descendant CNC Eagle DUB Boost, 170mm (S), 175mm (M, L, XL), Upgrade option: Rotor QX1 DM with SRAM chainring
Bottom Bracket

342 (33 drop), Press-fit
Front Derailleur

Direct mount (none included)
Rear Derailleur

SRAM NX Eagle
Shifters

SRAM NX Eagle, 12-speed

Components

Brakeset

Shimano MT501 BR500 Hydraulic Disc, Upgrade option: Shimano XT M8000 Hydraulic Disc, Shimano MT501 BR500
Handlebar

Race Face Aeffect 35, 10mm rise, 760mm width, Upgrade option: Race Face Next 35 Riser
Saddle

Selle Royal Custom Trail II 2043 HRN, Upgrade option: Selle Italia XR Trail
Seatpost

Race Face Aeffect 125mm dropper, 385mm length, Upgrade option: Crankbrothers Highline 150mm dropper, 425mm length, 31.6mm, Orbea quick release, 31.6mm, Orbea quick release
Stem

Race Face Aeffect R 35, 60mm (S, M), 70mm (L, XL), Upgrade option: Race Face Turbine 35
Headset

Acros Alloy, 1 1/8" - 1 1/2" integrated

Have some feedback or spotted an issue? Let us know.

FAQ

Q: How much is a 2019 Orbea Occam TR H20 Plus?

A 2019 Orbea Occam TR H20 Plus is typically priced around $3,299 USD when new. Be sure to shop around for the best price, and also look to the used market for a great deal.

Q: Where to buy a 2019 Orbea Occam TR H20 Plus?

The 2019 Orbea Occam TR H20 Plus may be purchased directly from Orbea.

Q: What size wheels does the 2019 Orbea Occam TR H20 Plus have?

The 2019 Orbea Occam TR H20 Plus has 27.5" wheels.

Q: What size 2019 Orbea Occam TR H20 Plus should I get?

The 2019 Orbea Occam TR H20 Plus comes in sizes S - 29", M - 29", L - 29", XL - 29". After measuring your height, use the size chart below to find the typical Orbea Occam TR H20 Plus size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm)	Rider Height (in)	Frame Size
148cm - 158cm	4'10" - 5'2"	XS
158cm - 168cm	5'2" - 5'6"	S
168cm - 178cm	5'6" - 5' 10"	M
178cm - 185cm	5'10" - 6'1"	L
185cm - 193cm	6'1" - 6'4"	XL
193cm - 198cm	6'4" - 6'6"	XXL
