Image of Haibike XDURO AllMtn 10.0
2018

Haibike XDURO AllMtn 10.0

Haibike XDURO 2018

6400

E-Mountain Trail

Colour / Silver/red/black

Size / S, M, L, XL

Weight / 49 lb 2.6 oz (22,300 g)

Manufacturer Website

At a glance

The 2018 Haibike XDURO AllMtn 10.0 is a E-Mountain and Trail Aluminium / Alloy mountain bike. It sports 27.5" wheels, is priced at $6,400 USD, comes in a range of sizes, including S, M, L, XL, has Fox suspension and a Shimano drivetrain. The bike is part of Haibike's XDURO range of mountain bikes. As a pedal-assisted e-mountain bike, the Haibike XDURO AllMtn 10.0 is powered by a Yamaha PW-X System, 80Nm, 500W motor and a Yamaha Lithium Ion with Yamaha quick charger 4A, 500 Wh battery.

Internal cable routing, Post mount disc brakes, Haibike eConnect system has a GPS transmitter, GSM chip as well as Bluetooth transmitter for anti-theft detection, emergency notification, and route recording

Where To Buy

Reviews

Specifications

Frameset
  • Frame
    Aluminium 6061, hydroformed tubes, Gravity Casting Interface, skid plate and internal cable routing
  • Fork
    FOX 34 Float Factory, Lockout, Boost, 150mm
  • Shock
    FOX Float DPX2 Factory
  • Motor
    Yamaha PW-X System, 80Nm, 500W
  • Battery
    Yamaha Lithium Ion with Yamaha quick charger 4A, 500 Wh
Wheels
  • Hubs
    DT Swiss HX 1501, Front: Boost, 15mm x 110mm
    Rear: Boost, 12mm x 148mm
  • Wheels
    DT Swiss HX 1501
  • Wheel Size
    27.5"
  • Spokes
    DT Swiss
  • Tires
    Maxxis Minion DHF
Drivetrain
  • Chain
    455mm, N/A, 32/44 tooth, FSA, Aluminum, KMC X10e
  • Crank
    Haibike Xduro
  • Bottom Bracket
    -10mm drop
  • Front Derailleur
    Shimano SLX M7000
  • Rear Derailleur
    Shimano Deore XT M786 Shadow Plus, 20-speed
  • Shifters
    Shimano Deore XT M780, Rapidfire, 10-speed
Components
  • Brakeset
    Magura MT7 with 203mm rotors, Magura MT7 HC, aluminium
  • Handlebar
    Haibike Components TheBar +++ Gravity, 780mm width
  • Saddle
    Prologo Scratch T2.0
  • Seatpost
    KS LEV-DX, 31.6mm, Quick release, 31.6mm, Quick release
  • Stem
    Haibike Components The Stem +++, 31.8mm clamp
  • Grips
    Haibike MTB Griffe
  • Headset
    A-Head, cartridge, aluminium

FAQ

Q: How much is a 2018 Haibike XDURO AllMtn 10.0?

A 2018 Haibike XDURO AllMtn 10.0 is typically priced around $6,400 USD when new. Be sure to shop around for the best price, and also look to the used market for a great deal.

Q: Where to buy a 2018 Haibike XDURO AllMtn 10.0?

The 2018 Haibike XDURO AllMtn 10.0 may be purchased directly from Haibike.

Q: How much does a 2018 Haibike XDURO AllMtn 10.0 weigh?

A 2018 Haibike XDURO AllMtn 10.0 weights 49 lb 2.6 oz (22,300 g).

Q: What size wheels does the 2018 Haibike XDURO AllMtn 10.0 have?

The 2018 Haibike XDURO AllMtn 10.0 has 27.5" wheels.

Q: What size 2018 Haibike XDURO AllMtn 10.0 should I get?

The 2018 Haibike XDURO AllMtn 10.0 comes in sizes S, M, L, XL. After measuring your height, use the size chart below to find the typical Haibike XDURO AllMtn 10.0 size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm) Rider Height (in) Frame Size
148cm - 158cm 4'10" - 5'2" XS
158cm - 168cm 5'2" - 5'6" S
168cm - 178cm 5'6" - 5' 10" M
178cm - 185cm 5'10" - 6'1" L
185cm - 193cm 6'1" - 6'4" XL
193cm - 198cm 6'4" - 6'6" XXL
