2025

Megamo TRACK RACE AXS

Name: 2025 Megamo TRACK RACE AXS
Brand: Megamo

Cross Country

Compare

Size / SM, MD, LG, XL

Manufacturer Website

At a glance

The 2025 Megamo TRACK RACE AXS is an Cross Country Carbon mountain bike. It comes in a range of sizes, including SM, MD, LG, XL and a SRAM drivetrain. The bike is part of Megamo's TRACK range of mountain bikes.

Where To Buy

Megamo

Megamo TRACK RACE AXS

Loading more...

Reviews

Specifications

Frameset

Frame

Track Full Carbon Construction FSC Technology BB92 Carbon Swingarm Boost 12x148mm

Wheels

Wheels

DT Swiss XRC 1501 Carbon
Tires

Maxxis Ardent Race 29x2,35 - Tubeless Ready, EXO, 3C Maxx Speed, Foldable, 120tpi, Pirelli Scorpion XC H 29x2,4 ProWall - Tubeless Ready, 120tpi

Drivetrain

Crank

SRAM GX 12s T-type 34T
Bottom Bracket

BB86/BB92, press-fit
Rear Derailleur

SRAM GX Eagle AXS 12s
Shifters

SRAM Eagle AXS Controller

Components

Brakeset

Shimano XT 8100
Handlebar

Full Integrated Carbon handlebar Megamo
Saddle

Selle Italia Novus Boost Evo Superflow Titanium
Seatpost

Fox Transfer SL Factory Kashima 31,6. Internal routing, remote.
Headset

Integrated Full Internal Cable Routing

Have some feedback or spotted an issue? Let us know.

Geometry

Frame Size	SM	MD	LG	XL
Bottom Bracket Drop	36mm	36mm	36mm	36mm
Bottom Bracket Height	338mm	338mm	338mm	338mm
Chainstay Length	431mm	431mm	431mm	431mm
Front Center	703mm	728mm	759mm	792mm
Head Tube Angle	66.5°	66.5°	66.5°	66.5°
Head Tube Length	96mm	96mm	111mm	130mm
Rake	44mm	44mm	44mm	44mm
Reach	410mm	435mm	460mm	485mm
Seat Tube Angle	75.6°	75.6°	75.6°	75.6°
Seat Tube Length	422mm	441mm	482mm	520mm
Stack	599mm	599mm	613mm	630mm
Stack Reach Ratio	1.461	1.377	1.333	1.299
Top Tube Length	563mm	588mm	617mm	647mm
Trail	115mm	115mm	115mm	115mm
Wheel Kind Front	29	29	29	29
Wheel Kind Rear	29	29	29	29
Wheelbase	1132mm	1157mm	1188mm	1221mm

Have some feedback or spotted an issue? Let us know.

FAQ

Q: Where to buy a 2025 Megamo TRACK RACE AXS?

The 2025 Megamo TRACK RACE AXS may be purchased directly from Megamo.

Q: What size 2025 Megamo TRACK RACE AXS should I get?

The 2025 Megamo TRACK RACE AXS comes in sizes SM, MD, LG, XL. After measuring your height, use the size chart below to find the typical Megamo TRACK RACE AXS size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm)	Rider Height (in)	Frame Size
148cm - 158cm	4'10" - 5'2"	XS
158cm - 168cm	5'2" - 5'6"	S
168cm - 178cm	5'6" - 5' 10"	M
178cm - 185cm	5'10" - 6'1"	L
185cm - 193cm	6'1" - 6'4"	XL
193cm - 198cm	6'4" - 6'6"	XXL
