2025

Superior eXF 9049 B

Name: 2025 Superior eXF 9049 B
Brand: Superior

E-Mountain Trail

Compare

Size / SM, MD, LG, XL

Manufacturer Website

At a glance

The 2025 Superior eXF 9049 B is a E-Mountain and Trail Aluminium / Alloy mountain bike. It comes in a range of sizes, including SM, MD, LG, XL and a Shimano drivetrain. The bike is part of Superior's eXF range of mountain bikes. As a pedal-assisted e-mountain bike, the Superior eXF 9049 B is powered by a BOSCH Performance Line CX, 85Nm motor and a BOSCH PowerTube, 750Wh battery.

Where To Buy

Superior

Superior eXF 9049 B

Loading more...

Reviews

Specifications

Frameset

Frame

SUE03-CXBES3, Alu X6 Ultralite MTB Trail, Advanced e-MTB Geometry, Travel 160/140 mm, BOSCH CX Performance 5G ready, Integrated battery up to 750Wh, 3D alloy one pice link, Alloy swingarm, Boost 12x148 mm, Inner cable routing, Dropped seat post ready
Fork

DT Swiss F535, Tapered, 15x110mm axle, 160mm travel
Shock

DT Swiss R535, size 230x65mm, OL
Motor

BOSCH Performance Line CX, 85Nm
Battery

BOSCH PowerTube, 750Wh

Wheels

Wheels

DT Swiss H 1900 SPLINE®, CL, 15x110mm, Tubeless Ready
Tires

Schwalbe Nobby Nic Evo, SuperTrail, TL-Easy, 29x2.60"", ADDIX SpeedGrip

Drivetrain

Chain

SHIMANO DEORE CN-M6100
Crank

ONE Race, Alloy
Bottom Bracket

Bosch, press-fit
Rear Derailleur

SHIMANO XT RD-M8100, Shadow Plus Design
Shifters

SHIMANO DEORE XT SL-M8100-IR, RAPIDFIRE Plus, 12-speed

Components

Brakeset

SHIMANO XT M8120, 4 piston, hydraulic disc brake
Handlebar

ONE Alloy, 12mm rise, 35mm
Saddle

Fizi:k Aidon X5, Alloy
Seatpost

ONE Sport Dropper Post, Alloy, 30.9mm
Stem

ONE ICR, Alloy, 35mm, 0°
Headset

ACROS AZX-1051S, ICR, ZS56/28.6 - ZS56/40, BlockLock 120°, Stainless Bearings

Have some feedback or spotted an issue? Let us know.

Geometry

Frame Size	SM	MD	LG	XL
Bottom Bracket Drop	27mm	27mm	27mm	27mm
Bottom Bracket Height	347mm	347mm	347mm	347mm
Chainstay Length	446mm	446mm	446mm	446mm
Crank Length	165mm	165mm	165mm	170mm
Front Center	806mm	806mm	826mm	846mm
Handlebar Width	760mm	760mm	760mm	760mm
Head Tube Angle	64°	64°	64°	64°
Head Tube Length	120mm	120mm	120mm	120mm
Rake	44mm	44mm	44mm	44mm
Reach	465mm	465mm	485mm	505mm
Seat Tube Angle	78°	77°	77°	77°
Seat Tube Length	393mm	420mm	440mm	490mm
Stack	625mm	625mm	625mm	625mm
Stack Reach Ratio	1.344	1.344	1.289	1.238
Stem Length	35mm	50mm	50mm	50mm
Top Tube Length	598mm	610mm	630mm	650mm
Trail	134mm	134mm	134mm	134mm
Wheel Kind Front	29	29	29	29
Wheel Kind Rear	29	29	29	29
Wheelbase	1251mm	1251mm	1271mm	1291mm

Have some feedback or spotted an issue? Let us know.

FAQ

Q: Where to buy a 2025 Superior eXF 9049 B?

The 2025 Superior eXF 9049 B may be purchased directly from Superior.

Q: What size 2025 Superior eXF 9049 B should I get?

The 2025 Superior eXF 9049 B comes in sizes SM, MD, LG, XL. After measuring your height, use the size chart below to find the typical Superior eXF 9049 B size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm)	Rider Height (in)	Frame Size
148cm - 158cm	4'10" - 5'2"	XS
158cm - 168cm	5'2" - 5'6"	S
168cm - 178cm	5'6" - 5' 10"	M
178cm - 185cm	5'10" - 6'1"	L
185cm - 193cm	6'1" - 6'4"	XL
193cm - 198cm	6'4" - 6'6"	XXL
