Superior eXF 9039
Superior eXF 20255999
E-Mountain TrailSize / MD, LG, XL
Manufacturer WebsiteAt a glance
The 2025 Superior eXF 9039 is a E-Mountain and Trail Aluminium / Alloy mountain bike. It is priced at €5,999 EUR, comes in a range of sizes, including MD, LG, XL, has RockShox suspension and a Shimano drivetrain. The bike is part of Superior's eXF range of mountain bikes. As a pedal-assisted e-mountain bike, the Superior eXF 9039 is powered by a SHIMANO STEPS EP6, 85Nm motor and a DARFON, 630Wh battery.Where To Buy
Superior
Superior eXF 9039Reviews
Specifications
Frameset
-
FrameSU-E03-STEPS, Alu X6 Ultralite MTB Trail SUE03, Advanced e-MTB Geometry, Travel 130 mm, SHIMANO STEPS ready, Prepared to 630Wh integrated battery, 3D alloy one piece link, Alloy swingarm, SR dropout, Boost 12x148 mm, Inner cable routing, Dropped seat post ready
-
ForkRockShox Revelation RC, Tapered, DebonAir, 15x110mm axle, 140mm travel
-
ShockRockShox Deluxe Select+ RL, size 210x50mm
-
MotorSHIMANO STEPS EP6, 85Nm
-
BatteryDARFON, 630Wh
Wheels
-
WheelsDT Swiss H 1900 SPLINE®, CL, 15x110mm, Tubeless Ready
-
TiresSchwalbe Nobby Nic Evo, SuperTrail, TL-Easy, 29x2.60"", ADDIX SpeedGrip
Drivetrain
-
ChainSHIMANO DEORE CN-M6100
-
CrankSHMANO FC-EM600
-
Bottom BracketSTEPS, press-fit
-
Rear DerailleurSHIMANO SLX RD-M7100, Shadow Plus Design
-
ShiftersSHIMANO DEORE SL-M6100-IR, RAPIDFIRE Plus, 12-speed
Components
-
BrakesetSHIMANO M6120, 4 piston, hydraulic disc brake
-
HandlebarONE Alloy, 20mm rise, 31.8mm
-
SaddleFizi:k Terra Aidon X5, Alloy
-
SeatpostONE Sport Dropper Post, Alloy, 30.9mm
-
StemONE ICR, Alloy, 31.8mm, 0°
-
HeadsetACROS AZX-1051, ICR, ZS56/28.6 - ZS56/40, BlockLock 120°
Geometry
| Frame Size | MD | LG | XL |
| Bottom Bracket Drop | 20mm | 20mm | 20mm |
| Bottom Bracket Height | 354mm | 354mm | 354mm |
| Chainstay Length | 433mm | 433mm | 433mm |
| Crank Length | 165mm | 165mm | 170mm |
| Front Center | 764mm | 775mm | 792mm |
| Handlebar Width | 780mm | 780mm | 780mm |
| Head Tube Angle | 66° | 66° | 66° |
| Head Tube Length | 100mm | 110mm | 120mm |
| Rake | 43mm | 43mm | 42mm |
| Reach | 459mm | 466mm | 479mm |
| Seat Tube Angle | 74.5° | 74.5° | 74.5° |
| Seat Tube Length | 431mm | 482mm | 533mm |
| Stack | 599mm | 608mm | 618mm |
| Stack Reach Ratio | 1.305 | 1.305 | 1.29 |
| Stem Length | 60mm | 60mm | 80mm |
| Top Tube Length | 625mm | 635mm | 650mm |
| Trail | 120mm | 120mm | 121mm |
| Wheel Kind Front | 29 | 29 | 29 |
| Wheel Kind Rear | 29 | 29 | 29 |
| Wheelbase | 1196mm | 1207mm | 1224mm |
FAQ
Q: How much is a 2025 Superior eXF 9039?
A 2025 Superior eXF 9039 is typically priced around €5,999 EUR when new. Be sure to shop around for the best price, and also look to the used market for a great deal.
Q: Where to buy a 2025 Superior eXF 9039?
The 2025 Superior eXF 9039 may be purchased directly from Superior.
Q: What size 2025 Superior eXF 9039 should I get?
The 2025 Superior eXF 9039 comes in sizes MD, LG, XL. After measuring your height, use the size chart below to find the typical Superior eXF 9039 size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.
| Rider Height (cm) | Rider Height (in) | Frame Size |
|---|---|---|
| 148cm - 158cm | 4'10" - 5'2" | XS |
| 158cm - 168cm | 5'2" - 5'6" | S |
| 168cm - 178cm | 5'6" - 5' 10" | M |
| 178cm - 185cm | 5'10" - 6'1" | L |
| 185cm - 193cm | 6'1" - 6'4" | XL |
| 193cm - 198cm | 6'4" - 6'6" | XXL |
