Image of Superior eXC 6.3
2025

Superior eXC 6.3

Superior eXC 2025

E-Mountain Trail
Compare

Size / SM, MD, LG, XL

Manufacturer Website

At a glance

The 2025 Superior eXC 6.3 is a E-Mountain and Trail mountain bike. It comes in a range of sizes, including SM, MD, LG, XL, has SR Suntour suspension and a Shimano drivetrain. The bike is part of Superior's eXC range of mountain bikes. As a pedal-assisted e-mountain bike, the Superior eXC 6.3 is powered by a BOSCH Performance Line, 75Nm motor and a BOSCH PowerTube, 625Wh battery.

Where To Buy

Reviews

Specifications

Frameset
  • Frame
    SU-EXC, Alu 6061 T6, Sport eMTB Geometry, Smooth Welding, Bosch system Powertube 625Wh battery ready, Inner Cable Routing
  • Fork
    SR Suntour XCR32, Tapered, 15x110mm axle, 120mm travel
  • Motor
    BOSCH Performance Line, 75Nm
  • Battery
    BOSCH PowerTube, 625Wh
Wheels
  • Hubs
    SHIMANO FH-TC500-HM-B, 32H, CL, 12X148mm, THRU Type AXLE
  • Wheels
    STARS J30D, Disc, 32H
  • Spokes
    SAPIM Galvanized Black
  • Tires
    Schwalbe Hurricane Performance, 29x2.25, ADDIX
Drivetrain
  • Chain
    SHIMANO CN-LG500
  • Crank
    ONE Sport, Alloy
  • Bottom Bracket
    Bosch, press-fit
  • Rear Derailleur
    SHIMANO CUES RD-U4000, Shadow Design
  • Shifters
    SHIMANO CUES SL-U4000-9R, RAPIDFIRE Plus, 9-speed
Components
  • Brakeset
    SHIMANO MT200, hydraulic disc brake
  • Handlebar
    ONE Alloy, 25mm rise, 31.8mm
  • Saddle
    Selle Royal Vivo
  • Seatpost
    ONE Sport, Alloy, 30.9mm
  • Stem
    ONE ICR, Alloy, 31.8mm, Adjustable
  • Headset
    ACROS AZF-604, ZS56/28.6 - ZS56/40, BlockLock 120°

Geometry

Frame Size SM MD LG XL
Bottom Bracket Drop 60mm 60mm 60mm 60mm
Bottom Bracket Height 314mm 314mm 314mm 314mm
Chainstay Length 500mm 500mm 500mm 500mm
Crank Length 170mm 170mm 170mm 170mm
Front Center 682mm 703mm 728mm 749mm
Handlebar Width 720mm 720mm 720mm 720mm
Head Tube Angle 67° 67° 67° 67°
Head Tube Length 130mm 140mm 150mm 160mm
Rake 46mm 46mm 46mm 44mm
Reach 382mm 399mm 420mm 440mm
Seat Tube Angle 73.7° 73.7° 74° 74.2°
Seat Tube Length 406mm 457mm 510mm 559mm
Stack 643mm 652mm 662mm 671mm
Stack Reach Ratio 1.683 1.634 1.576 1.525
Stem Length 65mm 65mm 65mm 90mm
Top Tube Length 570mm 590mm 610mm 630mm
Trail 109mm 109mm 109mm 111mm
Wheel Kind Front 29 29 29 29
Wheel Kind Rear 29 29 29 29
Wheelbase 1176mm 1197mm 1222mm 1243mm

FAQ

Q: Where to buy a 2025 Superior eXC 6.3?

The 2025 Superior eXC 6.3 may be purchased directly from Superior.

Q: What size 2025 Superior eXC 6.3 should I get?

The 2025 Superior eXC 6.3 comes in sizes SM, MD, LG, XL. After measuring your height, use the size chart below to find the typical Superior eXC 6.3 size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm) Rider Height (in) Frame Size
148cm - 158cm 4'10" - 5'2" XS
158cm - 168cm 5'2" - 5'6" S
168cm - 178cm 5'6" - 5' 10" M
178cm - 185cm 5'10" - 6'1" L
185cm - 193cm 6'1" - 6'4" XL
193cm - 198cm 6'4" - 6'6" XXL
