At a glance
The 2025 Megamo TRACK BUFF-MEGAMO is an Trail Carbon mountain bike. It comes in a range of sizes, including SM, MD, LG, XL, has Fox suspension and a Shimano drivetrain. The bike is part of Megamo's TRACK range of mountain bikes.Where To Buy
Megamo
Megamo TRACK BUFF-MEGAMOReviews
Specifications
Frameset
-
FrameTrack Full Carbon Construction FSC Technology BB92 Carbon Swingarm Boost 12x148mm SuperLight version
-
ForkFOX 34 Performance, 120mm Travel, Step-Cast, Grip, 3 Position, QR Axle 15x110, 1.5 Tapered, 44mm offset
-
ShockFOX Float SL Performance, 190x45mm, Evol SV + Remote Up
Wheels
-
HubsMegamo Hubs, Front axle 15 x 110 mm, Rear axle 12 x 148 mm BOOST
-
WheelsMegamo 29 SL 27 ASY - Race, 27mm Tubeless ready Aluminium rim
-
TiresPirelli Scorpion XC H Prowall 29 x 2.4
Drivetrain
-
CrankShimano XT M8120 Chainring 32T 12-Speed, Crankset S size 170mm / M, L, XL size 175mm
-
Bottom BracketBSA, 73mm, threaded
-
Rear DerailleurShimano XT M8100, Shadow Plus 12-Speed
-
ShiftersShimano Deore 6100 Speed Rapidfire Plus, 12-Speed
Components
-
BrakesetShimano MT500 Hydraulic Disc 2-Piston SM-RT26 180/160mm
-
HandlebarFull Integrated Carbon Handlebar / S, M size 60x760mm / L, XL size 80x760mm
-
SaddleSelle Italia Model X Superflow
-
SeatpostMegamo Ø 31,6mm telescopic seat post, remote adjustment S size 80 mm Drop / M, L size 100 mm Drop / XL size 120 mm Drop
-
HeadsetIntegrated Full Internal Cable Routing
Geometry
| Frame Size | SM | MD | LG | XL |
| Bottom Bracket Drop | 36mm | 36mm | 36mm | 36mm |
| Bottom Bracket Height | 338mm | 338mm | 338mm | 338mm |
| Chainstay Length | 431mm | 431mm | 431mm | 431mm |
| Front Center | 703mm | 728mm | 759mm | 792mm |
| Head Tube Angle | 66.5° | 66.5° | 66.5° | 66.5° |
| Head Tube Length | 96mm | 96mm | 111mm | 130mm |
| Rake | 44mm | 44mm | 44mm | 44mm |
| Reach | 410mm | 435mm | 460mm | 485mm |
| Seat Tube Angle | 75.6° | 75.6° | 75.6° | 75.6° |
| Seat Tube Length | 422mm | 441mm | 482mm | 520mm |
| Stack | 599mm | 599mm | 613mm | 630mm |
| Stack Reach Ratio | 1.461 | 1.377 | 1.333 | 1.299 |
| Top Tube Length | 563mm | 588mm | 617mm | 647mm |
| Trail | 115mm | 115mm | 115mm | 115mm |
| Wheel Kind Front | 29 | 29 | 29 | 29 |
| Wheel Kind Rear | 29 | 29 | 29 | 29 |
| Wheelbase | 1132mm | 1157mm | 1188mm | 1221mm |
FAQ
Q: Where to buy a 2025 Megamo TRACK BUFF-MEGAMO?
The 2025 Megamo TRACK BUFF-MEGAMO may be purchased directly from Megamo.
Q: What size 2025 Megamo TRACK BUFF-MEGAMO should I get?
The 2025 Megamo TRACK BUFF-MEGAMO comes in sizes SM, MD, LG, XL. After measuring your height, use the size chart below to find the typical Megamo TRACK BUFF-MEGAMO size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.
| Rider Height (cm) | Rider Height (in) | Frame Size |
|---|---|---|
| 148cm - 158cm | 4'10" - 5'2" | XS |
| 158cm - 168cm | 5'2" - 5'6" | S |
| 168cm - 178cm | 5'6" - 5' 10" | M |
| 178cm - 185cm | 5'10" - 6'1" | L |
| 185cm - 193cm | 6'1" - 6'4" | XL |
| 193cm - 198cm | 6'4" - 6'6" | XXL |
