2024

Canyon Neuron:ON CF 9

Name: 2024 Canyon Neuron:ON CF 9
Brand: Canyon

E-Mountain Trail

Compare

Size / SM, MD, LG, XL

Manufacturer Website

At a glance

The 2024 Canyon Neuron:ON CF 9 is a E-Mountain and Trail Carbon mountain bike. It is priced at €6,999 EUR, comes in a range of sizes, including SM, MD, LG, XL, has RockShox suspension and a SRAM drivetrain. The bike is part of Canyon's Neuron:ON range of mountain bikes. As a pedal-assisted e-mountain bike, the Canyon Neuron:ON CF 9 is powered by a Bosch Performance Line CX motor and a SRAM Powerpack, Bosch PowerTube 750Wh battery.

Where To Buy

Canyon

Canyon Neuron:ON CF 9

Loading more...

Reviews

Specifications

Frameset

Frame

Canyon Neuron:ON, Elegant, compliant, light Canyon Neuron:ON carbon frame, 130 mm rear travel in sizes M-XL (125 mm in sizes XS-S). Incredible kinematics thanks to Triple Phase Suspension design. Integrated battery. Boost standard rear axle (148 mm). Post mount brakes (180 mm rotors)., Axle dimension: 12x148 mm, Material: Carbon (CF)
Fork

Rockshox Pike Ultimate, Travel: 140 mm, Fork steer tube diameter: 1 1/8"" - 1,5", Offset: 44 mm, Weight: 2.34 kg
Shock

RockShox Deluxe Select R, Weight: 375 g
Motor

Bosch Performance Line CX
Battery

SRAM Powerpack, Bosch PowerTube 750Wh

Wheels

Wheels

DT SWISS HX1700, Rotor mount: IS 6-bolt, Weight: 1.13 kg, DT Swiss HX1700, Axle dimension: 15x110 mm, Rotor mount: IS 6-bolt, Rim height: 21 mm, Hub Technology: Spline, Inner width: 30 mm, Rim material: Aluminium, Weight: 1.00 kg
Tires

Schwalbe Nobby Nic 29x2.4 black skin, Width: 2.4""

Drivetrain

Chain

SRAM GX Eagle Transmission
Crank

SRAM X1
Bottom Bracket

BSA, 73mm, threaded
Rear Derailleur

SRAM GX Eagle AXS Transmission, Weight: 462 g
Shifters

SRAM AXS Pod, Weight: 67 g

Components

Brakeset

SRAM Code RSC
Handlebar

Canyon:ON HB0056 Riser bar, Aluminum, 780mm width, 35mm clamp diameter, 20mm rise
Saddle

Fizik Terra Alpaca X5, Weight: 230 g
Seatpost

Iridium Dropper Post, Move more freely on steep descents, by dropping down saddle with the press of a handlebar-mounted button. With internal cabling., Clamp diameter: 30,9 mm, Material: Aluminium (AL), Weight: 567 g
Stem

Canyon:ON ST0031, Canyon E-MTB stem., Length: 45 mm, Fork steer tube diameter: 1 1/8"", Clamping diameter: 35,0 mm
Grips

Canyon Lock-On Grips

Have some feedback or spotted an issue? Let us know.

Geometry

Frame Size	SM	MD	LG	XL
Bottom Bracket Drop	36mm	36mm	36mm	36mm
Bottom Bracket Height	338mm	338mm	338mm	338mm
Chainstay Length	450mm	450mm	450mm	450mm
Crank Length	165mm	165mm	165mm	165mm
Front Center	755mm	784mm	808mm	837mm
Front Travel	140mm	140mm	140mm	140mm
Handlebar Width	760mm	780mm	780mm	780mm
Head Tube Angle	65.5°	65.5°	65.5°	65.5°
Head Tube Length	120mm	130mm	140mm	150mm
Rake	44mm	43mm	39mm	39mm
Reach	435mm	460mm	485mm	510mm
Rear Travel	140mm	140mm	140mm	140mm
Seat Tube Angle	68.6°	69.3°	69.9°	70.2°
Seat Tube Length	420mm	440mm	460mm	480mm
Stack	631mm	641mm	650mm	659mm
Stack Reach Ratio	1.451	1.393	1.34	1.292
Standover Height	773mm	779mm	785mm	790mm
Stem Length	45mm	45mm	45mm	45mm
Top Tube Length	587mm	614mm	641mm	668mm
Trail	122mm	123mm	128mm	128mm
Wheel Kind Front	29	29	29	29
Wheel Kind Rear	29	29	29	29
Wheelbase	1203mm	1232mm	1256mm	1285mm

Have some feedback or spotted an issue? Let us know.

FAQ

Q: How much is a 2024 Canyon Neuron:ON CF 9?

A 2024 Canyon Neuron:ON CF 9 is typically priced around €6,999 EUR when new. Be sure to shop around for the best price, and also look to the used market for a great deal.

Q: Where to buy a 2024 Canyon Neuron:ON CF 9?

The 2024 Canyon Neuron:ON CF 9 may be purchased directly from Canyon.

Q: What size 2024 Canyon Neuron:ON CF 9 should I get?

The 2024 Canyon Neuron:ON CF 9 comes in sizes SM, MD, LG, XL. After measuring your height, use the size chart below to find the typical Canyon Neuron:ON CF 9 size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm)	Rider Height (in)	Frame Size
148cm - 158cm	4'10" - 5'2"	XS
158cm - 168cm	5'2" - 5'6"	S
168cm - 178cm	5'6" - 5' 10"	M
178cm - 185cm	5'10" - 6'1"	L
185cm - 193cm	6'1" - 6'4"	XL
193cm - 198cm	6'4" - 6'6"	XXL
