Image of BiXS Access-E20 FS
2024

BiXS Access-E20 FS

BiXS ACCESS-E20 2024

E-Mountain Trail
Compare

Size / MD, LG, XL

Manufacturer Website

At a glance

The 2024 BiXS Access-E20 FS is a E-Mountain and Trail Aluminium / Alloy mountain bike. It comes in a range of sizes, including MD, LG, XL, has SR Suntour suspension and a Shimano drivetrain. The bike is part of BiXS's ACCESS-E20 range of mountain bikes. As a pedal-assisted e-mountain bike, the BiXS Access-E20 FS is powered by a YAMAHA PW-X 2 SERIES, 250 WATT motor and a SIMPLO, 36V, 630Wh battery.

Where To Buy

Reviews

Specifications

Frameset
  • Frame
    E-ACTIVE GEOMETRY, ALLOY 6061, 130mm TRAVEL, ALLOY ROCKER, DROPOUT 148x12mm BOOST, 29""
  • Fork
    SUNTOUR XCR34 AIR 29"", LOR, 15x110mm AXLE, TAPERED, 120mm TRAVEL, REBOUND LOCKOUT
  • Shock
    SUNTOUR EDGE LOR, 205X60, TRUNNION MOUNT, HARDWARE: 21.8mmx8mm
  • Motor
    YAMAHA PW-X 2 SERIES, 250 WATT
  • Battery
    SIMPLO, 36V, 630Wh
Wheels
  • Hubs
    SHIMANO FH-TC500-HM-B, 32 HOLES, 12x148mm BOOST THRU AXLE
  • Wheels
    ALEXRIMS EM-30, 32 HOLES, INNER WIDTH 30mm, 29""
  • Tires
    SCHWALBE JONNY WATTS PERFORMANCE RACE GUARD, 29x2.35""
Drivetrain
  • Chain
    SHIMANO CN-HG900-11
  • Crank
    FSA CK-320/ISIS, 34 TEETH
  • Rear Derailleur
    SHIMANO DEORE RD-M5100 SGS SHADOW PLUS DESIGN, 11-SPEED
  • Shifters
    SHIMANO DEORE SL-M5100
Components
  • Brakeset
    SHIMANO BR-MT410, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:200mm, R:180mm ROTORS
  • Handlebar
    BIXS HB-RB12W RIZER BAR, 760mm, 9°ANGLE, 15mm RISE, 31.8mm
  • Saddle
    ERGON SFC30
  • Seatpost
    KIND SHOCK RAGEi, M & L: 125mm, XL: 150mm TRAVEL, SOUTHPAW-ALLOY REMOTE LEVER, 31.6mm
  • Stem
    BIXS AS-M03, 0°ANGLE, 31.8mm CLAMP
  • Headset
    FSA NO.55R 1.5"" / 558

Geometry

Frame Size MD LG XL
Bottom Bracket Drop 34mm 34mm 34mm
Bottom Bracket Height 340mm 340mm 340mm
Chainstay Length 479mm 479mm 479mm
Crank Length 170mm 170mm 170mm
Front Center 745mm 757mm 769mm
Head Tube Angle 68° 68° 68°
Head Tube Length 135mm 140mm 145mm
Rake 54mm 54mm 54mm
Reach 440mm 450mm 460mm
Seat Tube Angle 74° 74° 74°
Seat Tube Length 430mm 480mm 520mm
Stack 643mm 647mm 652mm
Stack Reach Ratio 1.461 1.438 1.417
Stem Length 40mm 40mm 40mm
Top Tube Length 611mm 623mm 634mm
Trail 93mm 93mm 93mm
Wheel Kind Front 29 29 29
Wheel Kind Rear 29 29 29
Wheelbase 1222mm 1234mm 1246mm

FAQ

Q: Where to buy a 2024 BiXS Access-E20 FS?

The 2024 BiXS Access-E20 FS may be purchased directly from BiXS.

Q: What size 2024 BiXS Access-E20 FS should I get?

The 2024 BiXS Access-E20 FS comes in sizes MD, LG, XL. After measuring your height, use the size chart below to find the typical BiXS Access-E20 FS size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm) Rider Height (in) Frame Size
148cm - 158cm 4'10" - 5'2" XS
158cm - 168cm 5'2" - 5'6" S
168cm - 178cm 5'6" - 5' 10" M
178cm - 185cm 5'10" - 6'1" L
185cm - 193cm 6'1" - 6'4" XL
193cm - 198cm 6'4" - 6'6" XXL
