BiXS Peak-E14 Mint
BiXS PEAK-E14 2024 E-Mountain TrailSize / A, B, C, D, E, F, G, H, I, J, K, LG
Manufacturer WebsiteAt a glance
The 2024 BiXS Peak-E14 Mint is a E-Mountain and Trail Aluminium / Alloy mountain bike. It comes in a range of sizes, including A, B, C, D, E, F, G, H, I, J, K, LG, has RockShox suspension and a Shimano drivetrain. The bike is part of BiXS's PEAK-E14 range of mountain bikes. As a pedal-assisted e-mountain bike, the BiXS Peak-E14 Mint is powered by a YAMAHA PW-X 3 SERIES, 250 WATT motor and a SIMPLO, 36V, 630WH battery.Where To Buy
BiXS
BiXS Peak-E14 MintReviews
Specifications
Frameset
-
FrameE-TRAIL GEOMETRY, ALLOY 6061, 140MM TRAVEL, ALLOY ROCKER, DROPOUT 148X12MM BOOST, 29""
-
ForkROCK SHOX 35 SILVER TK SOLO AIR 29"", 15X110MM AXLE, TAPERED, 150MM TRAVEL, REBOUND, COMP. TO LOCK
-
ShockROCK SHOX DELUX SELECT+ RT, LEVER, 185X55MM, TRUNNION MOUNT, HARDWARE: 20MMX8MM
-
MotorYAMAHA PW-X 3 SERIES, 250 WATT
-
BatterySIMPLO, 36V, 630WH
Wheels
-
HubsSUNRINGLE WHEELSET DUROC 37SD COMP, 32 HOLES, 12X148MM BOOST, THRU AXLE
-
TiresONZA IBEX, KEVLAR FOLDABLE, TUBELESS READY, 29X2.6""
Drivetrain
-
ChainKMC E12 SPORT, EPT ANTI-RUST
-
CrankFSA CK320, ISIS, BOOST, STEEL CHAINRING, 34 TEETH
-
Rear DerailleurSHIMANO DEORE RD-M6100 SGS SHADOW PLUS DESIGN, 12-SPEED
-
ShiftersSHIMANO DEORE SL-M6100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV
Components
-
BrakesetSHIMANO BR-MT420, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:203MM, R:203MM ROTORS
-
HandlebarBIXS RIZER BAR, 780MM, 9° BACKSWEEP, 15MM RISE, 35MM
-
SaddleBIXS VL-3575
-
SeatpostKIND SHOCK RAGEI, S: 100MM, M: 125MM, L: 150MM, XL: 170MM TRAVEL, WESTY LEVER REMOTE, 31.6MM
-
StemBIXS 0°ANGLE, 35MM CLAMP
-
HeadsetACROS CUSTOMIZED FOR INTEGRATED CABLE ROUTING, 1.5"" BLOCK LOCK
Geometry
| Frame Size | A | B | C | D | E | F | G | H | I | J | K | LG |
| Wheel Kind Front | 29 | 29 | 29 | 29 | 29 | 29 | 29 | 29 | 29 | 29 | 29 | 29 |
| Wheel Kind Rear | 29 | 29 | 29 | 29 | 29 | 29 | 29 | 29 | 29 | 29 | 29 | 29 |
FAQ
Q: Where to buy a 2024 BiXS Peak-E14 Mint?
The 2024 BiXS Peak-E14 Mint may be purchased directly from BiXS.
Q: What size 2024 BiXS Peak-E14 Mint should I get?
The 2024 BiXS Peak-E14 Mint comes in sizes A, B, C, D, E, F, G, H, I, J, K, LG. After measuring your height, use the size chart below to find the typical BiXS Peak-E14 Mint size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.
| Rider Height (cm) | Rider Height (in) | Frame Size |
|---|---|---|
| 148cm - 158cm | 4'10" - 5'2" | XS |
| 158cm - 168cm | 5'2" - 5'6" | S |
| 168cm - 178cm | 5'6" - 5' 10" | M |
| 178cm - 185cm | 5'10" - 6'1" | L |
| 185cm - 193cm | 6'1" - 6'4" | XL |
| 193cm - 198cm | 6'4" - 6'6" | XXL |
