Trek Fuel EXe 9.8 XT
Trek Fuel-Exe 2023 E-MountainWeight / M - 18.10 kg / 39.91 lbs (with TLR sealant, no tubes)
Manufacturer WebsiteAt a glance
The 2023 Trek Fuel EXe 9.8 XT is an E-Mountain Carbon mountain bike. It sports 29" wheels, has RockShox suspension and a Shimano drivetrain. The bike is part of Trek's Fuel-Exe range of mountain bikes. As a pedal-assisted e-mountain bike, the Trek Fuel EXe 9.8 XT is powered by a TQ-HPR50, 300 watt, 50 Nm motor and a TQ 360Wh battery.Where To Buy
Trek
Trek Fuel EXe 9.8 XTReviews
Specifications
Frameset
-
FrameOCLV Mountain Carbon, removable battery, internal routing, alloy rocker link, 34.9mm seat tube, upper chain guide mount, 55mm chainline, Mino Link, ABP, Boost148, UDH, 140mm travel
-
ForkRockShox Lyrik Select+, DebonAir spring, Charger 2.1 RC damper, tapered steerer, 44mm offset, Boost110, 15mm Maxle Stealth, 150mm travel
-
ShockRockShox Super Deluxe Select+ RT, 205mm x 60mm
-
MotorTQ-HPR50, 300 watt, 50 Nm
-
BatteryTQ 360Wh
Wheels
-
WheelsBontrager Line Elite 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle
-
Wheel Size29"
-
TiresBontrager TLR sealant, 6oz
Drivetrain
-
ChainE*thirteen E*spec, 32T alloy ring, 55mm chainline
-
CrankE*thirteen E*spec Race carbon, 34T, 165mm length
-
Rear DerailleurShimano XT M8100, long cage
-
ShiftersShimano XT M8100, 12 speed
Components
-
BrakesetShimano XT M8120 4-piston hydraulic disc
-
SaddleBontrager Arvada, austenite rails, 138mm width
FAQ
Q: Where to buy a 2023 Trek Fuel EXe 9.8 XT?
The 2023 Trek Fuel EXe 9.8 XT may be purchased directly from Trek.
Q: How much does a 2023 Trek Fuel EXe 9.8 XT weigh?
A 2023 Trek Fuel EXe 9.8 XT weights M - 18.10 kg / 39.91 lbs (with TLR sealant, no tubes).
Q: What size wheels does the 2023 Trek Fuel EXe 9.8 XT have?
The 2023 Trek Fuel EXe 9.8 XT has 29" wheels.
Q: What size 2023 Trek Fuel EXe 9.8 XT should I get?
After measuring your height, use the size chart below to find the typical Trek Fuel EXe 9.8 XT size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.
| Rider Height (cm) | Rider Height (in) | Frame Size |
|---|---|---|
| 148cm - 158cm | 4'10" - 5'2" | XS |
| 158cm - 168cm | 5'2" - 5'6" | S |
| 168cm - 178cm | 5'6" - 5' 10" | M |
| 178cm - 185cm | 5'10" - 6'1" | L |
| 185cm - 193cm | 6'1" - 6'4" | XL |
| 193cm - 198cm | 6'4" - 6'6" | XXL |
