Image of Schwinn Mesa 3

Schwinn Mesa 3

Schwinn Mesa 2022


Cross Country

Size / SM, MD, LG

Manufacturer Website

At a glance

The 2022 Schwinn Mesa 3 is an Cross Country Aluminium / Alloy mountain bike. It sports 27.5" wheels, is priced at $579 USD, comes in a range of sizes, including SM, MD, LG and a Shimano drivetrain. The bike is part of Schwinn's Mesa range of mountain bikes.

Where To Buy

Schwinn Logo
Schwinn Mesa 3
Loading more...



  • Frame
    6061 aluminum, 26"" / 27.5" mountain tuned geometry, Epicenter seat stays, 10 mm x 135 mm dropout, replaceable hanger, 1 1/8 in headtube
  • Fork
    Zoom HL565, 26""/27.5", steel steerer, 9mm x 100mm QR, 80mm travel
  • Hubs
    Schwinn mountain, aluminum, 10 mm x 135 mm QR, 32H
  • Wheels
    Alex DC26, aluminum, double wall, 32H
  • Wheel Size
  • Spokes
    14G, stainless steel
  • Tires
    Schwinn mountain, 26 in / 27.5 in x 2.1 in, wire bead
  • Chain
    KMC Z7
  • Crank
    Schwinn aluminum mountain, 42/34/24T
  • Bottom Bracket
    VP, cartridge, square taper, 68 mm
  • Front Derailleur
    Shimano Tourney, 31.8 mm clamp
  • Rear Derailleur
    Shimano Tourney RD-TY300
  • Shifters
    Shimano EF41 EZ-FIRE, 21-speed
  • Brakeset
    Radius V993, linear pull, aluminum
  • Handlebar
    Schwinn, steel, 20 mm rise, 25.4 mm clamp
  • Saddle
    Schwinn mountain, steel rails
  • Seatpost
    Aluminum, 300 mm, 15 mm offset, 27.2 mm
  • Stem
    Schwinn, aluminum, threadless, 10° rise, 25.4 mm clamp
  • Grips
    Schwinn mountain Kraton
  • Headset
    Threadless, EC34, loose ball bearing


Q: How much is a 2022 Schwinn Mesa 3?

A 2022 Schwinn Mesa 3 is typically priced around $579 USD when new. Be sure to shop around for the best price, and also look to the used market for a great deal.

Q: Where to buy a 2022 Schwinn Mesa 3?

The 2022 Schwinn Mesa 3 may be purchased directly from Schwinn.

Q: What size wheels does the 2022 Schwinn Mesa 3 have?

The 2022 Schwinn Mesa 3 has 27.5" wheels.

Q: What size 2022 Schwinn Mesa 3 should I get?

The 2022 Schwinn Mesa 3 comes in sizes SM, MD, LG. After measuring your height, use the size chart below to find the typical Schwinn Mesa 3 size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm) Rider Height (in) Frame Size
148cm - 158cm 4'10" - 5'2" XS
158cm - 168cm 5'2" - 5'6" S
168cm - 178cm 5'6" - 5' 10" M
178cm - 185cm 5'10" - 6'1" L
185cm - 193cm 6'1" - 6'4" XL
193cm - 198cm 6'4" - 6'6" XXL
