KTM Macina Mini Me 441

Frameset

• Frame

  6061 alloy
• Fork

  SR Suntour XCR Air LO, 63mm
• Motor

  Bosch Active Plus Gen.3, 50Nm max torque
• Battery

  Bosch PowerTube, integrated, removable, 400 Wh

Wheels

• Hubs

  Front: Shimano MT200, 100mm quick release
  Rear: Shimano MT400, 12x148mm Boost, HG driver
• Wheels

  Ambrosio Sport, 32 hole
• Spokes

  Front: DT Swiss Champion 2.0
  Rear: DT Swiss Alpine II 2.34
• Tires

  Maxxis Rekon, folding, 24" x 2.2"

Drivetrain

• Chain

  420mm, None, FSA, steel, direct mount, 38 tooth, with chainguard, Shimano E6070, e-bike, 9-speed
• Crank

  KTM BNI, 152mm length
• Bottom Bracket

  40mm drop
• Rear Derailleur

  Shimano Alivio M3100, 9-speed, SHADOW RD, SGS cage
• Shifters

  Shimano Alivio M3100, 9-speed, with gear display

Components

• Brakeset

  Shimano MT200, 2-piston, Shimano 160mm CENTER LOCK rotors (RT30 front, EM300 rear), Shimano MT201
• Handlebar

  KTM Comp Flat, 560mm width
• Saddle

  KTM Kid
• Seatpost

  KTM Comp, 300mm length, 30.9mm, Quick release, 30.9mm, Quick release
• Stem

  KTM Team MTB, 7° rise
• Grips

  KTM Comp, lock-on
• Headset

  ACROS, angle limit
