Image of Ghost E-Riot AM Advanced
2022

Ghost E-Riot AM Advanced

Ghost E-Riot 2022

E-Mountain Enduro

Colour / JadeBlue/BlackMatte, BlackMatte/Orange

Size / SM, MD, LG, XL

Manufacturer Website

At a glance

The 2022 Ghost E-Riot AM Advanced is a E-Mountain and Enduro Carbon mountain bike. It sports 29" and 27.5" wheels, comes in a range of sizes, including SM, MD, LG, XL, has RockShox suspension and a SRAM drivetrain. The bike is part of Ghost's E-Riot range of mountain bikes. As a pedal-assisted e-mountain bike, the Ghost E-Riot AM Advanced is powered by a Bosch Performance CX Gen4 motor and a Bosch PowerTube, integrated, 750 Wh battery.

- TractionLink rear suspension design

- SM has 27.5″ wheels; MD/LG/XL have 29″ wheels

- Cables routed under downtube cable cover

- SRAM UDH (Universal Derailleur Hanger)

- Includes Bosch 4A battery charger

- European price: 5699 EUR

Where To Buy

Reviews

Specifications

Frameset
  • Frame
    Carbon front triangle, alloy rear triangle, one-piece rocker, molded chainstay protection
  • Fork
    RockShox 35 Silver TK, Solo Air spring, 160mm
  • Shock
    RockShox Super Deluxe Select R, trunnion mount, 205mm x 65mm
  • Motor
    Bosch Performance CX Gen4
  • Battery
    Bosch PowerTube, integrated, 750 Wh
Wheels
  • Hubs
    Shimano MT400, 15x110mm Boost front, 12x148mm Boost rear with HG driver
  • Wheels
    WTB ST i30, 30mm inner width
  • Wheel Size
    29" 27.5"
  • Tires
    Front: Maxxis Minion DHF, 3C MaxxTerra, EXO+, 2.5”
    Rear: Maxxis Minion DHR II, 3C MaxxTerra, EXO+, 2.6”
Drivetrain
  • Chain
    435mm, 455mm, MRP upper slider, e*thirteen e*spec Plus, 34 tooth, 12-speed
  • Crank
    e*thirteen e*spec Plus
  • Bottom Bracket
    24mm drop, 38mm drop
  • Rear Derailleur
    SRAM SX Eagle, 12-speed
  • Shifters
    SRAM SX Eagle, 12-speed, Single Click
Components
  • Brakeset
    Shimano MT420, 4-piston, 203mm rotors, Shimano MT420
  • Handlebar
    Ground Fiftyone, 31.8mm clamp diameter, SM: 760mm width, 15mm rise; MD/LG: 780mm width, 15mm rise; XL: 780mm width, 40mm rise
  • Saddle
    fi'zi:k Terra Aidon
  • Seatpost
    Ghost Alpha 1 dropper, 34.9mm, Single bolt, 34.9mm, Single bolt
    Drop:
    125mm (SM)
    150mm (MD)
    170mm (LG/XL)
  • Stem
    Ground Fiftyone, 45mm length, 31.8mm bar clamp
  • Headset
    ACROS Block Lock AZX-582, 135° rotation limit, 44mm upper, 56mm lower

FAQ

Q: Where to buy a 2022 Ghost E-Riot AM Advanced?

The 2022 Ghost E-Riot AM Advanced may be purchased directly from Ghost.

Q: What size wheels does the 2022 Ghost E-Riot AM Advanced have?

The 2022 Ghost E-Riot AM Advanced has 29" and 27.5" wheels.

Q: What size 2022 Ghost E-Riot AM Advanced should I get?

The 2022 Ghost E-Riot AM Advanced comes in sizes SM, MD, LG, XL. After measuring your height, use the size chart below to find the typical Ghost E-Riot AM Advanced size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm) Rider Height (in) Frame Size
148cm - 158cm 4'10" - 5'2" XS
158cm - 168cm 5'2" - 5'6" S
168cm - 178cm 5'6" - 5' 10" M
178cm - 185cm 5'10" - 6'1" L
185cm - 193cm 6'1" - 6'4" XL
193cm - 198cm 6'4" - 6'6" XXL
