At a glance

The 2021 Spot is an Cross Country Carbon mountain bike. It sports 29" and 27.5" wheels, has Fox suspension and a SRAM drivetrain. The bike is part of Spot's Rocker range of mountain bikes.

• Kobe 3 Slider Dropouts allow chainstay length adjustment and singlespeed setups, • Internal shifter/dropper post cable routing with full-length internal conduits, • External brake hose routing via Groovy Guides along down tube, • Photos show 6-Star AXS build

Where To Buy

Spot Logo
Spot
Spot
Loading more...

Reviews

Specifications

Frameset
  • Frame
    Full carbon frame, molded chainstay and down tube protection
  • Fork
    FOX FLOAT 34 Step-Cast (SC) Factory, FIT4 damper, 3-position lever, 44mm offset, 120mm
Wheels
  • Hubs
    Stan's NoTubes wheelset, 110x15mm Boost front, 148x12mm Boost rear with XD driver
  • Wheels
    29"": Stan's NoTubes Crest MK3 wheelset, 27.5+: Stan's NoTubes Baron MK3 wheelset
  • Wheel Size
    29" 27.5"
  • Spokes
    Stan's NoTubes wheelset
  • Tires
    29"" Front: Schwalbe Racing Ray, 29" x 2.25", 29" Rear: Schwalbe Racing Ralph, 29" x 2.25", 27.5+ Front/Rear: Maxxis Rekon+, 27.5" x 2.8"
Drivetrain
  • Chain
    438-453mm, None, SRAM X1 Eagle, 32 tooth, SRAM GX Eagle, 12-speed
  • Crank
    SRAM X1 Eagle Carbon DUB, 170mm length
  • Bottom Bracket
    320mm (50mm drop), SRAM DUB, 73mm BSA threaded
  • Rear Derailleur
    SRAM X01 Eagle, 12-speed
  • Shifters
    SRAM GX Eagle, 12-speed
Components
  • Brakeset
    SRAM Level TLM, 2-piston, SRAM CenterLine CENTER LOCK rotors (180mm front, 160mm rear), SRAM Level TLM
  • Handlebar
    ENVE M6, 31.8mm clamp diameter, 25mm rise, Width: 740mm (SM/MD), 760mm (LG), 780mm (XL)
  • Saddle
    Spot MTB
  • Seatpost
    BikeYoke Revive dropper, 31.6mm, Single bolt, 31.6mm, Single bolt
    Drop:
    125mm (SM)
    160mm (MD)
    185mm (LG/XL)
  • Stem
    Race Face Turbine, 60mm length, 31.8mm bar clamp
  • Grips
    Spot, lock-on
  • Headset
    Cane Creek 40, ZS44 upper, ZS56 lower

FAQ

Q: What size wheels does the 2021 Spot have?

The 2021 Spot has 29" and 27.5" wheels.

Q: What size 2021 Spot should I get?

After measuring your height, use the size chart below to find the typical Spot size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm) Rider Height (in) Frame Size
148cm - 158cm 4'10" - 5'2" XS
158cm - 168cm 5'2" - 5'6" S
168cm - 178cm 5'6" - 5' 10" M
178cm - 185cm 5'10" - 6'1" L
185cm - 193cm 6'1" - 6'4" XL
193cm - 198cm 6'4" - 6'6" XXL
