Diamondback Rely 2
Diamondback Rely 20191500.00
Cross CountryColour / Light Grey
Size / S/15" / Rider Height: 5'3" - 5'5" , M/17" / Rider Height: 5'5" - 5'8" , L/19" / Rider Height: 5'8" - 5'11"
Manufacturer WebsiteAt a glance
The 2019 Diamondback Rely 2 is an Cross Country mountain bike. It sports 27.5" wheels, is priced at $1,500 USD, comes in a range of sizes, including S/15" / Rider Height: 5'3" - 5'5" , M/17" / Rider Height: 5'5" - 5'8" , L/19" / Rider Height: 5'8" - 5'11", has RockShox suspension and a SRAM drivetrain. The bike is part of Diamondback's Rely range of mountain bikes.Where To Buy
Diamondback
Diamondback Rely 2Reviews
Specifications
Frameset
-
FrameRely Women's 27.5" Plus 6061-T6 Weapons Grade Aluminum w/ Double Butted Formed Top Tube, Down Tube, Seatstays, Tapered Head Tube, ISCG-05 Tabs, 148x12mm Boost Spec Dropouts, w/ Replaceable Hanger
-
ForkRockshox Judy Gold RL, 120mm Travel, Solo Air Spring, External Rebound Adjust w/ Turnkey Lockout, Magnesium Lowers, Alloy 1.5" Tapered Steerer Tube, Boost 110x15mm Thru-axle
Wheels
-
HubsFront: 32h Alloy, Boost 110x15mm Thru-axle, Sealed Cartridge Bearings, w/ CNC Disc Mount
Rear: 32h Alloy, Boost 148x12mm Thru-axle, 2 Sealed Cartridge Bearing, for SRAM XD w/ CNC Disc Mount -
WheelsDiamondback Alex MD35, Tubeless ready, 32h
-
Wheel Size27.5"
-
Spokes14g Stainless Steel
-
TiresVee Rubber T-Fatty 27.5x2.8
Drivetrain
-
ChainKMC X11EL, 11 Speed
-
CrankRaceface Æffect Cinch w/ Steel 28T "Narrow Wide"
-
Bottom BracketRaceface Outboard Bearing
-
Rear DerailleurSRAM NX X-Horizon, 11 Speed
-
ShiftersSRAM NX 11 Speed X-Actuation Trigger
Components
-
BrakesetSRAM Level T Hydraulic Disc, w/ 180mm Front / Rear Centerline Rotors
-
HandlebarDB35 Alloy, 760mm Wide, 15mm Rise, 35mm Bar Bore
-
SaddleDB Women's Performance MTB Saddle
-
SeatpostJD 7075 Alloy Internal Dropper, w/ 1x Lever, 30.9mm
-
StemDB35 Alloy, 60mm, 35mm Bar Bore
-
GripsNew DB "Flanged" Lock-on, 135mm Silicone
-
HeadsetFSA NO.57, Sealed Cartridge for Tapered Headtube
FAQ
Q: How much is a 2019 Diamondback Rely 2?
A 2019 Diamondback Rely 2 is typically priced around $1,500 USD when new. Be sure to shop around for the best price, and also look to the used market for a great deal.
Q: Where to buy a 2019 Diamondback Rely 2?
The 2019 Diamondback Rely 2 may be purchased directly from Diamondback.
Q: What size wheels does the 2019 Diamondback Rely 2 have?
The 2019 Diamondback Rely 2 has 27.5" wheels.
Q: What size 2019 Diamondback Rely 2 should I get?
The 2019 Diamondback Rely 2 comes in sizes S/15" / Rider Height: 5'3" - 5'5" , M/17" / Rider Height: 5'5" - 5'8" , L/19" / Rider Height: 5'8" - 5'11". After measuring your height, use the size chart below to find the typical Diamondback Rely 2 size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.
| Rider Height (cm) | Rider Height (in) | Frame Size |
|---|---|---|
| 148cm - 158cm | 4'10" - 5'2" | XS |
| 158cm - 168cm | 5'2" - 5'6" | S |
| 168cm - 178cm | 5'6" - 5' 10" | M |
| 178cm - 185cm | 5'10" - 6'1" | L |
| 185cm - 193cm | 6'1" - 6'4" | XL |
| 193cm - 198cm | 6'4" - 6'6" | XXL |
