Image of Cube Sting Hybrid 120 HPC SL 500
2019

Cube Sting Hybrid 120 HPC SL 500

Cube Sting Hybrid 120 2019

E-Mountain Trail

Colour / Carbon´n´berry

Size / 16", 18", 20", 22"

Weight / 50 lb 0.7 oz (22,700 g)

Manufacturer Website

At a glance

The 2019 Cube Sting Hybrid 120 HPC SL 500 is a E-Mountain and Trail Carbon mountain bike. It sports 29" and 27.5" wheels, comes in a range of sizes, including 16", 18", 20", 22", has Fox suspension and a Shimano drivetrain. The bike is part of Cube's Sting Hybrid 120 range of mountain bikes. As a pedal-assisted e-mountain bike, the Cube Sting Hybrid 120 HPC SL 500 is powered by a Bosch Drive Unit Performance CX (75Nm) Cruise (250Watt) motor and a Bosch PowerTube 500 with Bosch 2A charger, 500 Wh battery.

FSP 4-Link suspension design, Integrated cable routing, dropper post ready, Integrated post mount rear brake, Adaptable X12 derailleur hanger, Dropper post options available, 27.5″ wheels for 16″ frame, 29″ wheels for 18″, 20″, 22″ frame

Where To Buy

Reviews

Specifications

Frameset
  • Frame
    C:62 monocoque advanced twin mold technology, aluminium 6061 T6 rear triangle, integrated battery
  • Fork
    FOX 34 Rhythm, GRIP, 2-position, sweep adjust, e-bike optimized, 15mm x 110mm, 120mm
  • Shock
    FOX Float DPS EVOL, open/medium/firm mode, 184mm x 44mm, 30x8mm upper mount, 30x8mm lower mount
  • Motor
    Bosch Drive Unit Performance CX (75Nm) Cruise (250Watt)
  • Battery
    Bosch PowerTube 500 with Bosch 2A charger, 500 Wh
Wheels
  • Hubs
    Front: Shimano HB-MT400-B, Boost, Center Lock, 15QR x 110mm
    Rear: Shimano FH-MT400-B, Boost, Center Lock, 12mm x 148mm
  • Wheels
    Cube EX30, 32 hole, tubeless ready
  • Wheel Size
    29" 27.5"
  • Tires
    Schwalbe Nobby Nic, Performance, 29 x 2.60" (27.5 for 16" frame)
Drivetrain
  • Chain
    476.5, 490, N/A, 15 tooth, KMC X11e, EcoProTeQ
  • Crank
    FSA CK-745, 170mm
  • Bottom Bracket
    29.5mm drop, 30mm drop
  • Rear Derailleur
    Shimano XT RD-M8000-DGS, Shadow Plus, 11-speed
  • Shifters
    Shimano SLX SL-M7000
Components
  • Brakeset
    Shimano BR-MT520/BR-MT500 with 180mm rotors (front and rear), Shimano BR-MT520/BR-MT500
  • Handlebar
    Newmen Evolution 318.20, 760mm width
  • Saddle
    Cube Natural Fit Active Race WS
  • Seatpost
    Newmen Evolution, 31.6mm, Cube Varioclose, 31.6mm, Cube Varioclose
  • Stem
    Newmen Evolution 318.4, 31.8mm diameter
  • Grips
    Cube Race SL 29.5, single clamp
  • Headset
    FSA Orbit I-t, integrated

FAQ

Q: Where to buy a 2019 Cube Sting Hybrid 120 HPC SL 500?

The 2019 Cube Sting Hybrid 120 HPC SL 500 may be purchased directly from Cube.

Q: How much does a 2019 Cube Sting Hybrid 120 HPC SL 500 weigh?

A 2019 Cube Sting Hybrid 120 HPC SL 500 weights 50 lb 0.7 oz (22,700 g).

Q: What size wheels does the 2019 Cube Sting Hybrid 120 HPC SL 500 have?

The 2019 Cube Sting Hybrid 120 HPC SL 500 has 29" and 27.5" wheels.

Q: What size 2019 Cube Sting Hybrid 120 HPC SL 500 should I get?

The 2019 Cube Sting Hybrid 120 HPC SL 500 comes in sizes 16", 18", 20", 22". After measuring your height, use the size chart below to find the typical Cube Sting Hybrid 120 HPC SL 500 size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm) Rider Height (in) Frame Size
148cm - 158cm 4'10" - 5'2" XS
158cm - 168cm 5'2" - 5'6" S
168cm - 178cm 5'6" - 5' 10" M
178cm - 185cm 5'10" - 6'1" L
185cm - 193cm 6'1" - 6'4" XL
193cm - 198cm 6'4" - 6'6" XXL
