Canyon Lux CF 9.0 Pro Race Team

Frameset

• Frame

  Canyon Lux CF 29, Single piece carbon rear triangle, Carbon Flex Pivot, Carbon monocoque main triangle, Single piece aluminium rocker, Internal Cable Routing, Internal routing for dropper seatposts, Chain suck protection plate, Press-Fit Bottom Bracket, Tapered Steerer, Tapered Head Tube
• Fork

  RockShox, RockShox RS-1, Travel: 100 mm, Upside down design for better responsiveness, Predictive Steering for handling precision, Rapid Recovery damper for extra traction, X-LOC lockout remote
• Shock

  RockShox Monarch XX Full Sprint Remote, Hydraulic XLoc Full Sprint remote lockout system with floodgate, Dual Flow damping, Rebound adjustment, Compression adjustment

Wheels

• Wheels

  DT Swiss XRC 1200 Spline, UD Carbon rims, SPLINE® Technology, SPLINE® Hub body, DT Swiss Ratchet System
• Wheel Size

  29"
• Tires

  Maxxis IKON, 3C MaxxSpeed, Tubeless-Ready, 120tpi, Low rolling resistance

Drivetrain

• Chain

  SRAM X01 Eagle, SRAM XO1 Eagle
• Crank

  SRAM XX1 Eagle, SRAM XX1 EAGLE Carbon, 12s, Carbon cranks, X-SYNC™ tooth profile for maximum chain control, Direct mount chainring, 24 mm axle
• Bottom Bracket

  SRAM GXP Pressfit
• Rear Derailleur

  SRAM XX1 Eagle, SRAM XX1 Eagle, 12s, X-Horizon derailleur, X-Actuation, X-Sync, Roller Bearing Clutch, Cage Lock, Long carbon cage, 12-speed
• Shifters

  SRAM XX1 Eagle, SRAM XX1 Eagle Grip Shift, Carbon fibre, 12-speed, X-Actuation

Components

• Brakeset

  SRAM Level Ultimate, SRAM Level Ultimate
• Handlebar

  Canyon H20 Flat CF, Width: 720 mm, Rise: +/- 5 mm, Backsweep: 9°, In-house developed Canyon handlebars with lightweight carbon construction and balanced geometry, Compliant with Canyon Category 3 testing standards
• Saddle

  Ergon SM30 Evo, Ergonomically shaped, 274g,, CrMo Rails
• Seatpost

  Kind Shock LEV CI
• Stem

  Canyon V14, Angle: +/- 6°, 1 1/8" Stem clamp, In-house developed Canyon stem with new clamping concept for added security, Hexagonal profile design for extra torsional stiffness, Compliant with Canyon Category 3 testing standards
• Grips

  Canyon Race Grip, Ultralight silicone grip, Specially adapted for grip shift, Outer diameter: 32 mm black
• Headset

  Cane Creek 40
