Image of Specialized Turbo Levo Hardtail Comp 6Fattie
2017

Specialized Turbo Levo Hardtail Comp 6Fattie

Specialized Turbo 2017

E-Mountain
Compare

At a glance

The 2017 Specialized Turbo Levo Hardtail Comp 6Fattie is an E-Mountain Aluminium / Alloy mountain bike. It has RockShox suspension and a SRAM drivetrain. The bike is part of Specialized's Turbo range of mountain bikes.

The Men’s Turbo Levo Hardtail Comp 6Fattie has all of the speed and nimble handling that our hardtail trail bikes are known for—only with a sophisticated Turbo boost. Then comes the efficient and powerful Turbo technology, mating the battery and motor into the M5 frame in a new way. The exclusive, custom-tuned motor smoothly and quietly assists with the pedal assisted power, from the 250W motor that makes climbing nearly effortless. The output is also fully adjustable to suit your terrain and enable you to conserve your energy where required. At the battery, you’ll find that it’s fully integrated with the down tube and easily removable for quick charging or swaps.

It has a lengthy lifespan for hitting long, out of the way trails and, along with the motor, is strategically placed for optimal weight distribution on the frame. This version has a durable build kit, with a 120mm RockShox Revelation Reba RL fork up front, SRAM DB5 brakes, and a SRAM one-by groupset controlling shift and drivetrain duties. It also features our revolutionary new 6Fattie wheel system that decreases deflection and dramatically increases traction, floatation, and fun over the trail. Add to this our powerful Mission Control App for full control of the Turbo technology and an integrated Trail Display with all of the ride metrics you need, and you’re looking at the future of hardtail trail bikes.

Where To Buy

Reviews

Specifications

Frameset
  • Frame
    Specialized M5 Premium Aluminium, Trail HT Geometry, integrated down tube battery, enclosed internal cable and Command Post IR routing, 148mm spacing
  • Fork
    RockShox Reba RL 29/27.5+, Fast Black uppers, Solo air, 15x110mm thru-axle, 100/120mm travel (frame size specific)
Wheels
  • Hubs
    Front: Specialized disc, alloy, sealed cartridge bearings, 110x15mm thru-axle, 24h
    Rear: Specialized disc, alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
  • Wheels
    Roval Traverse 650b, hookless alloy, 38mm inner width, 24/28h, tubeless ready
  • Spokes
    DT Swiss Industry, stainless
  • Tires
    [F] [R]
Drivetrain
  • Chain
    SRAM PC1031, 11-speed w/PowerLink
  • Crank
    Custom alloy crankarms
  • Bottom Bracket
    Integrated in motor
  • Rear Derailleur
    SRAM GX, Type 2.1, long cage, 10-speed
  • Shifters
    SRAM GX, 10-speed, trigger
  • Cassette
    Sunrace, 10-speed, 11-40t
  • Pedals
    Alloy platform
Components
  • Brakeset
    Front: SRAM DB5, hydraulic disc, custom 4-piston caliper, semi-organic pads, 200mm rotor
    Rear: SRAM DB5, hydraulic disc, 2-piston caliper, semi-organic pads, 200mm rotor
  • Handlebar
    Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 27mm rise, 750mm width
  • Saddle
    Body Geometry Henge Sport, steel rails, 143mm
  • Seatpost
    TranzX dropper, internal cable routing, remote lever, 30.9mm, S/M: 100mm, L/XL: 120mm travel
  • Stem
    Specialized, 3D-forged alloy, 4-bolt, 6-degree rise, 31.8mm clamp

FAQ

Q: What size 2017 Specialized Turbo Levo Hardtail Comp 6Fattie should I get?

After measuring your height, use the size chart below to find the typical Specialized Turbo Levo Hardtail Comp 6Fattie size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm) Rider Height (in) Frame Size
148cm - 158cm 4'10" - 5'2" XS
158cm - 168cm 5'2" - 5'6" S
168cm - 178cm 5'6" - 5' 10" M
178cm - 185cm 5'10" - 6'1" L
185cm - 193cm 6'1" - 6'4" XL
193cm - 198cm 6'4" - 6'6" XXL
