Image of Diamondback Mission 2
2017

Diamondback Mission 2

Diamondback Mission 2017

3499.99

Enduro

Colour / Grey

Size / SM (15.5"), MD (17"), LG (19"), XL (21")

Weight / 31 lb 14.4 oz (14,470 g)

Manufacturer Website

At a glance

The 2017 Diamondback Mission 2 is an Enduro Aluminium / Alloy mountain bike. It sports 27.5" wheels, is priced at $3,500 USD, comes in a range of sizes, including SM (15.5"), MD (17"), LG (19"), XL (21"), has Fox suspension and a Shimano drivetrain. The bike is part of Diamondback's Mission range of mountain bikes.

Knuckle Box Technology, Includes DB shock pump, DB torque wrench, tubeless valves, extra derailleur hanger, and mud guard

Where To Buy

Reviews

Specifications

Frameset
  • Frame
    6061-T6 weapons grade aluminum, hydroformed top tube, butted/formed down tube and seatstays
  • Fork
    FOX Performance 36 Float, open cartridge, 3-position lever, external rebound adjust, 36mm Easton aluminum stanchions, 110x15mm Boost thru-axle, 160mm
  • Shock
    FOX Float DPS EVOL Air, 3-position lever, rebound adjust, "LV" eyelet, 8.5" x 2.5"
Wheels
  • Hubs
    32 hole alloy, sealed cartridge bearing, 110x15mm Boost front, 142x12mm rear
  • Wheels
    Diamondback Blanchard 28R, tubeless compatible, 32 hole
  • Wheel Size
    27.5"
  • Spokes
    14g stainless steel
  • Tires
    WTB Vigilante Race, DNA compound, 60tpi, 27.5" x 2.3"
Drivetrain
  • Chain
    451mm, N/A, Race Face Aeffect, 32 tooth "Narrow Wide", KMC X11EL, 11-speed
  • Crank
    Race Face Aeffect
  • Bottom Bracket
    2mm drop, Race Face outboard bearing
  • Rear Derailleur
    Shimano SLX M7000, Shadow Plus, 11-speed
  • Shifters
    Shimano SLX M7000, I-Spec, 11-speed
Components
  • Brakeset
    Shimano SLX BR-M7000 Hydraulic Disc, metal cooling fin pads, 180mm rotors, Shimano SLX BR-M7000 Hydraulic with reach adjust
  • Handlebar
    DB35 alloy, 780mm width, 15mm rise, 35mm clamp
  • Saddle
    DB Race M-Series, Cromoly rails
  • Seatpost
    KS LEV Integra Dropper, SouthPaw remote, 30.9mm, Quick release, 30.9mm, Quick release
  • Stem
    DB35 alloy, 50mm length, 35mm clamp
  • Grips
    DB4L lock on, 135mm, Kraton

FAQ

Q: How much is a 2017 Diamondback Mission 2?

A 2017 Diamondback Mission 2 is typically priced around $3,500 USD when new. Be sure to shop around for the best price, and also look to the used market for a great deal.

Q: Where to buy a 2017 Diamondback Mission 2?

The 2017 Diamondback Mission 2 may be purchased directly from Diamondback.

Q: How much does a 2017 Diamondback Mission 2 weigh?

A 2017 Diamondback Mission 2 weights 31 lb 14.4 oz (14,470 g).

Q: What size wheels does the 2017 Diamondback Mission 2 have?

The 2017 Diamondback Mission 2 has 27.5" wheels.

Q: What size 2017 Diamondback Mission 2 should I get?

The 2017 Diamondback Mission 2 comes in sizes SM (15.5"), MD (17"), LG (19"), XL (21"). After measuring your height, use the size chart below to find the typical Diamondback Mission 2 size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm) Rider Height (in) Frame Size
148cm - 158cm 4'10" - 5'2" XS
158cm - 168cm 5'2" - 5'6" S
168cm - 178cm 5'6" - 5' 10" M
178cm - 185cm 5'10" - 6'1" L
185cm - 193cm 6'1" - 6'4" XL
193cm - 198cm 6'4" - 6'6" XXL
