Image of Specialized Pitch Sport 650b
2016

Specialized Pitch Sport 650b

Specialized Pitch 2016

Street

At a glance

The 2016 Specialized Pitch Sport 650b is an Street Aluminium / Alloy mountain bike. It has SR Suntour suspension and a Shimano drivetrain. The bike is part of Specialized's Pitch range of mountain bikes.

We know that picking a mountain bike can be a bit of daunting process, what with all of the options and technology floating around out there. But while some suspension platforms and tech pass like fads in the wind, hardtails have stuck around since the advent of the mountain bike. That’s why we built our Pitch Sport 650b around an aluminium hardtail design. The design allows the rear end to stay planted while you’re pedalling, so it has plenty to offer in the way of efficiency on climbs and on the flats. And with our acclaimed Sport Trail 650b Geometry and ample suspension up front, you’re guaranteed to feel confident and ready to rip when the trail tips downwards.

It’s everything you need to get there and get riding.

Where To Buy

Reviews

Specifications

Frameset
  • Frame
    Specialized A1 Premium Aluminium, Sport Trail 650b Geometry, butted tube sets, externally relieved head tube, forged dropouts, reinforced disc mount, replaceable alloy derailleur hanger
  • Fork
    Custom SR Suntour XCT 650b, custom Multi-Circuit Damping, coil spring, S: 80mm travel, M/L/XL: 100mm travel, preload adjust, 1-1/8"" steerer, alloy lowers, Hi-Ten 28mm stanchions, disc mount
Wheels
  • Hubs
    Front: Specialized Stout, Hi Lo disc, alloy, double-sealed, ground race, QR, 32h
    Rear: Specialized Stout, Hi Lo disc, alloy, double-sealed, loose ball bearings, QR, 32h
  • Wheels
    650b, disc, alloy, double-wall, pin joint, 25mm inner width, 32h
  • Spokes
    Stainless, 14g
  • Tires
    [F] [R]
Drivetrain
  • Chain
    KMC X8, 8-speed w/reusable MissingLink
  • Crank
    Stout, forged alloy construction, 8-speed
  • Bottom Bracket
    Square taper, cartridge bearings
  • Front Derailleur
    Shimano Altus, high mount, bottom swing, dual pull
  • Rear Derailleur
    Shimano Acera Shadow, 9-speed
  • Shifters
    Shimano Altus RapidFire Plus, SL type, optical display
  • Cassette
    Sunrace, 8-speed, 11-34t
  • Pedals
    Plastic, 9/16"", w/ reflectors
Components
  • Brakeset
    Front: Tektro Auriga, hydraulic disc, resin/metallic pads
    Rear: Tektro Auriga, hydraulic disc, resin/metallic pads
  • Handlebar
    Specialized Stout, double-butted 6061 alloy, 9-degree backsweep, 5-degree upsweep, 15mm rise, 31.8mm
  • Saddle
    Body Geometry mountain, steel rails, 143mm
  • Seatpost
    Alloy, 2-bolt, micro-adjust, 12.5mm offset, 30.9mm, anti-corrosion hardware
  • Stem
    Specialized, 3D forged alloy, 4-bolt, 6-degree rise

FAQ

Q: What size 2016 Specialized Pitch Sport 650b should I get?

After measuring your height, use the size chart below to find the typical Specialized Pitch Sport 650b size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm) Rider Height (in) Frame Size
148cm - 158cm 4'10" - 5'2" XS
158cm - 168cm 5'2" - 5'6" S
168cm - 178cm 5'6" - 5' 10" M
178cm - 185cm 5'10" - 6'1" L
185cm - 193cm 6'1" - 6'4" XL
193cm - 198cm 6'4" - 6'6" XXL
