Image of Specialized Fuse Comp 6Fattie
2016

Specialized Fuse Comp 6Fattie

Specialized Fuse 2016

Cross Country

At a glance

The 2016 Specialized Fuse Comp 6Fattie is an Cross Country mountain bike. It has SR Suntour suspension and a SRAM drivetrain. The bike is part of Specialized's Fuse range of mountain bikes.

Take a look at the world’s strongest man, and you’re not going to find some chiseled Adonis. You’re going to find someone who has more volume. Behind the extra surface area, though, there’s a man that can dominate a caber toss and run down the tarmac with a plane in tow. Mathematically, it could be broken down as more volume + versatility = dominance, and that’s exactly what’s at play with the Fuse Comp 6Fattie. Our 6Fattie Wheel System uplifts the Fuse to have more traction and control than any hardtail before it, while its no-nonsense build is custom spec’d to get the job done, no matter how rugged, technical, or hair raising that job might be.

Where To Buy

Reviews

Specifications

Frameset
  • Frame
    Specialized M4 Premium Aluminum, Trail 6Fattie Geometry, fully-butted w/ smooth welds, tapered head tube, tapered seat tube, forged 160mm disc mounts, 148mm thru-axle dropouts, replaceable alloy derailleur hanger
  • Fork
    SR Suntour Raidon 650+, air spring, S: 100mm travel, M/L/XL: 120mm travel, compression adjust, rebound adjust, tapered alloy steerer, alloy stanchions, 15x110mm thru-axle
Wheels
  • Hubs
    Front: Specialized Stout XC Pro 110, disc, alloy, cartridge bearings, 15x110mm thru-axle, 24h
    Rear: Specialized disc, alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
  • Wheels
    WTB Scraper i45 650b, double-wall, 45mm inner width, 18mm deep, TCS tubeless compatible, sleeved, 24/28h
  • Spokes
    Stainless, 14g, black
  • Tires
    Front: OE Purgatory Control -60 78-584 650b x 3.0"", 60 TPI
    Rear: Specialized 6Fattie Ground Control, 60TPI, 2Bliss Ready, folding bead, 650bx3.0""
Drivetrain
  • Chain
    KMC X10L, 10-speed w/reusable MissingLink
  • Crank
    Specialized Stout XC, forged alloy, 148-specific chain line, PF30, Cr-Mo spindle, 30T, 76mm BCD spider
  • Bottom Bracket
    BB30, sealed cartridge bearings
  • Rear Derailleur
    SRAM X7 Type 2.1, 10-speed, long cage
  • Shifters
    SRAM X5, 10-speed, trigger
  • Cassette
    Sunrace, 10-speed, 11-40t
  • Pedals
    Alloy platform
Components
  • Brakeset
    Front: TRP Slate X2, hydraulic 4-piston disc, I-spec compatible, metallic pads, 203/180 rotor
    Rear: TRP Slate X2, hydraulic 2-piston disc, I-spec compatible, metallic pads, 180/160mm rotor
  • Handlebar
    Specialized Stout, flat bar, double-butted 6061 alloy, 9-degree backsweep, 4-degree upsweep, 31.8mm
  • Saddle
    Body Geometry Henge Comp, thin padding, hollow Cr-Mo rails, 143mm
  • Seatpost
    TranzX dropper, internal cable routing, remote lever, 30.9mm, S: 80mm travel, M/L/XL: 100mm travel
  • Stem
    Specialized, 3D forged alloy, 4-bolt, 6-degree rise

FAQ

Q: What size 2016 Specialized Fuse Comp 6Fattie should I get?

After measuring your height, use the size chart below to find the typical Specialized Fuse Comp 6Fattie size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm) Rider Height (in) Frame Size
148cm - 158cm 4'10" - 5'2" XS
158cm - 168cm 5'2" - 5'6" S
168cm - 178cm 5'6" - 5' 10" M
178cm - 185cm 5'10" - 6'1" L
185cm - 193cm 6'1" - 6'4" XL
193cm - 198cm 6'4" - 6'6" XXL
