Image of Specialized Fatboy Trail
2016

Specialized Fatboy Trail

Specialized Fatboy 2016

Fat Bike

At a glance

The 2016 Specialized Fatboy Trail is an Fat Bike mountain bike. It has RockShox suspension and a SRAM drivetrain. The bike is part of Specialized's Fatboy range of mountain bikes.

Fat bikes sometimes get a bad rap as being just for the snow or the beach. This idea bums us out, though, because the characteristics of are Fatboy lend themselves perfectly to trail riding. That’s we purpose-built the Fatboy Trail for the rigors of trail riding. The fat wheel system and geometry work in tandem to keep you planted and run it wide open, while an air sprung suspension fork from RockShox does the heavy lifting when it comes to absorbing chatter and bumps. And when you factor in an efficient one-by drivetrain and powerful brakes, you get a bike that’ll help you find your limits on the trail and keep on coming back for more.

Where To Buy

Reviews

Specifications

Frameset
  • Frame
    Specialized M4 aluminum, fully-butted tubing w/ smooth welds, tapered head tube, post-mount disc dropouts, 190mm rear hub spacing, replaceable alloy derailleur hanger
  • Fork
    RockShox Bluto RL, Solo Air spring, Motion Control damping, external rebound adjust, mag lowers, tapered alloy steerer, 32mm alloy stanchions, disc mount, QR 15mm thru-axle for 150mm hub spacing
Wheels
  • Hubs
    [F] Specialized Stout XC 150, Hi Hi disc, double-sealed cartridge bearings, 15mm thru-axle, 32h [R] Specialized Stout XC 190, Hi Hi disc, alloy, sealed cartridge bearings, QR, 32h
  • Wheels
    Specialized Stout XC 90, disc, alloy, single wall, 90mm wide, sleeve joint, hookless design, 32h
  • Spokes
    Stainless, 14g, black
  • Tires
    [F] [R]
Drivetrain
  • Chain
    KMC X10L, 10-speed, w/ reusable MissingLink
  • Crank
    Specialized Stout XC Pro, forged alloy, 30mm alloy spindle, 100mm spindle width, 28T, 76mm BCD spider
  • Bottom Bracket
    BB30, sealed cartridge bearings
  • Rear Derailleur
    SRAM X7 Type 2.1, 10-speed, long cage
  • Shifters
    SRAM X7, 10-speed, trigger
  • Cassette
    Sunrace, 10-speed, 11-40t
  • Pedals
    Nylon, 1 pc. body, 9/16"", w/ reflectors
Components
  • Brakeset
    [F] Tektro Gemini, hydraulic disc, resin pads, i-Spec compatible, 180mm rotor [R] Tektro Gemini, hydraulic disc, resin pads, I-spec compatible, 160mm rotor
  • Handlebar
    Specialized Stout XC, double-butted 6061 alloy, 9-degree backsweep, 5-degree upsweep, 15mm rise, 31.8mm
  • Saddle
    Body Geometry Henge Sport, steel rails, 143mm
  • Seatpost
    TranzX YSP02 dropper, infinite adjust, external cable routing, remote lever, 30.9mm, S: 100mm travel, M/L/XL: 120mm travel
  • Stem
    Specialized Stout, 3D-forged alloy, 4-bolt, 6-degree rise, anti-corrosion hardware

FAQ

Q: What size 2016 Specialized Fatboy Trail should I get?

After measuring your height, use the size chart below to find the typical Specialized Fatboy Trail size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm)Rider Height (in)Frame Size
148cm - 158cm4'10" - 5'2"XS
158cm - 168cm5'2" - 5'6"S
168cm - 178cm5'6" - 5' 10"M
178cm - 185cm5'10" - 6'1"L
185cm - 193cm6'1" - 6'4"XL
193cm - 198cm6'4" - 6'6"XXL
