Image of Specialized Camber Elite Carbon 650b
2016

Specialized Camber Elite Carbon 650b

Specialized Camber 2016

Trail
Compare

At a glance

The 2016 Specialized Camber Elite Carbon 650b is an Trail Carbon mountain bike. It has Fox suspension and a SRAM drivetrain. The bike is part of Specialized's Camber range of mountain bikes.

Fast, playful, and ready to roll—the Camber Elite Carbon 650b is designed to deliver nimble handling and speed over the entire trail. In other words, it blends all of the playful trail bike characteristics that you want with the XC climbing prowess that you need. This is achieved by thoughtfully combining our FACT 9m carbon fibre Trail Chassis with a M5 alloy Camber FSR rear end. The combination results in blending light weight, rigidity, and durability in one package. At both ends of the bike, you’ll find a little extra travel to deliver 130mm of plush suspension—all without going overboard on big hit capability.

This means that you don’t have to sacrifice efficiency, weight, or sheer speed to ride how you want. And with our Trail 650b Geometry and lightweight, stiff, and smooth Concentric Pivot at the rear, we can guarantee it. The other trail component of the Camber is utility, and along these lines, it features our fully integrated SWAT Door at the down tube of the frame. Open it up, and you’re able to safely and securely house your ride essentials right where you want them—on the bike. For the build, we selected components that focus on strength and performance, like a SRAM one-by drivetrain, powerful Shimano SLX brakes, and a FOX 34 fork with ultra-stiff stanchions. It’s everything you need, and nothing that you don’t.

Where To Buy

Reviews

Specifications

Frameset
  • Frame
    FACT 9m carbon, Trail 650b Geometry, FACT IS carbon construction, M5 alloy rear triangle, SWAT Door integration, internal cable routing, 142mm dropouts, sealed cartridge bearing pivots, Brain shock mount, replaceable derailleur hanger, 130mm travel
  • Fork
    FOX 34 Performance 650b, 130mm travel, 3-position compression adjust, tapered steerer, 44mm offset, 15mm thru axle
  • Shock
    FOX/Specialized remote Position-Sensitive Mini Brain, AUTOSAG, Spike Valve, Brain Fade adjust I-Valve, 205x53mm
Wheels
  • Hubs
    Front: Roval Traverse, 15/20mm thru-axle, 24h
    Rear: Roval Traverse 142+, SRAM XX1 driver body, 12mm thru-axle, 28h
  • Wheels
    Roval Traverse 650b, alloy, disc, 29mm inner width, 24/28h
  • Spokes
    DT Swiss Revolution
  • Tires
    [F] [R]
Drivetrain
  • Chain
    KMC X11L, 11-speed, w/ reusable MissingLink
  • Crank
    SRAM GX-1000, 11-speed, PF30, 30T X-Sync ring, 94mm BCD spider
  • Bottom Bracket
    SRAM PF30, OS press-in bearings
  • Rear Derailleur
    SRAM X1, 11-speed, alloy cage
  • Shifters
    SRAM X1, 11-speed, trigger
  • Cassette
    SRAM XG-1175, 11-speed, 10-42t
  • Pedals
    Resin Test Ride Pedals with toe clips, CEN std.
Components
  • Brakeset
    Front: Shimano SLX, hydraulic disc, metallic pads, I-spec compatible, S/M: 180mm rotor, L/XL: 200mm rotor
    Rear: Shimano SLX, hydraulic disc, metallic pads, I-spec compatible, S/M: 160mm rotor, L/XL: 180mm rotor
  • Handlebar
    Specialized Trail, 7050 alloy, 8-degree backsweep, 6-degree upsweep, 25mm rise, 750mm width, 31.8mm
  • Saddle
    Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
  • Seatpost
    Command Post IRcc, cruiser control technology, micro-adjust height adjustable, alien head design, bottom mount cable routing, remote adjust SRL lever, 30.9mm, S: 100mm travel, M/L/XL: 125mm
  • Stem
    Specialized Trail, 3D forged alloy, 4-bolt, 6-degree rise

FAQ

Q: What size 2016 Specialized Camber Elite Carbon 650b should I get?

After measuring your height, use the size chart below to find the typical Specialized Camber Elite Carbon 650b size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm) Rider Height (in) Frame Size
148cm - 158cm 4'10" - 5'2" XS
158cm - 168cm 5'2" - 5'6" S
168cm - 178cm 5'6" - 5' 10" M
178cm - 185cm 5'10" - 6'1" L
185cm - 193cm 6'1" - 6'4" XL
193cm - 198cm 6'4" - 6'6" XXL
