Specialized Status I

Frameset

• Frame

  M4 hydroformed tubing, 1.5"" forged headtube, ISCG mounts, 135mm rear spacing, full-cartridge bearing pivots, 200mm travel
• Fork

  X-Fusion Vengeance R, coil spring, tapered alloy steerer, reb adj., 20mm thru-axle, 170mm travel
• Shock

  Custom X-Fusion Vector R, coil over w/ piggy back, adj. rebound, 8.5x2.5"", spring rate XS: 350, S: 400, M: 450, L: 500

Wheels

• Hubs

  Front: Specialized Hi Lo disc, sealed cartridge bearings, 20mm thru-axle, 32h
  Rear: Specialized disc, bolt-on 135mm, 36h
• Wheels

  P.Disc, 32mm wide, 36h
• Wheel Size

  26"
• Spokes

  Stainless, 14g
• Tires

  Front: Specialized Butcher SX, 2Bliss Ready, 26x2.3"", foldable aramid bead, dual compound, 60TPI
  Rear: Specialized Butcher SX, 2Bliss Ready, 26x2.3"", aramid bead, dual compound, 60 TPI

Drivetrain

• Chain

  KMC X-8, 8-speed, reusable Missing Link
• Crank

  Truvativ Ruktion, 165mm, w/ Status guide
• Bottom Bracket

  Truvativ Howitzer XR, oversize sealed outboard cartridge bearings, 73mm shell
• Rear Derailleur

  SRAM X7, 9-speed, short cage
• Shifters

  SRAM X4, 8-speed, trigger
• Cassette

  SRAM PG-830, 8-speed, 11-32
• Pedals

  Alloy platform, 9/16""

Components

• Brakeset

  Front: Avid Elixir 1, metallic pad, 200mm rotor
  Rear: Avid Elixir 1, metallic pad, 180mm rotor
• Handlebar

  Specialized DH, low-rise, 6061 alloy, 780mm wide, 9-degree backsweep, 6-degree upsweep, 31.8mm
• Saddle

  Specialized DH, 8mm steel rails
• Seatpost

  Specialized 6061 alloy, 2-bolt micro-adjust, no offset, 30.9mm, 300mm
• Stem

  Specialized P.Series MTB, forged alloy, 4-bolt, 40mm length, 31.8mm clamp
