Image of Specialized P.20 AM
2014

Specialized P.20 AM

Specialized P.20 2014

Street

At a glance

The 2014 Specialized P.20 AM is an Street mountain bike. The bike is part of Specialized's P.20 range of mountain bikes.

- The P’ in P.Bikes doesn’t stand for Pretty. No fluff and no sparkly stuff. Just bombproof rides that mix advanced technology and top-shelf materials with geometry proven in the street, park and dirt. Start rolling right on the P.20 AM, it’s built for shredding with a strong steel frame and fork, and quality components.

Where To Buy

Reviews

Specifications

Frameset
  • Frame
    Hi-Ten plain gauge steel, 20.5"" top tube, externally relieved MID BB shell, integrated headtube, seatstay-mounted U-brake bosses, 5mm thick dropouts for 14mm axle
  • Fork
    20"" BMX, 2mm thick Hi-Ten, tapered blades, 1-1/8"" threadless, 5mm Cr-Mo dropouts for 3/8"" axle
Wheels
  • Hubs
    Front: P.Series BMX, alloy, loose ball, solid axle, 36h
    Rear: P.Series BMX, alloy, loose ball, hollow axle, 36h
  • Wheels
    P.Series 20"", alloy double-wall, triple void, 35mm, 36h
  • Spokes
    Stainless, 14g (2.0mm)
  • Tires
    Front: Specialized Compound Street, 30TPI, wire bead, 20x2.3""
    Rear: Specialized Compound Street, 30TPI, wire bead, 20x2.3""
Drivetrain
  • Chain
    KMC Z-510H
  • Crank
    P.Crank, 3pc. Cr-Mo, tubular arms, 8-spline, 170mm
  • Bottom Bracket
    MID BB, 2x sealed cartridge bearings w/ 19mm, 8-spline spindle
  • Pedals
    Plastic platform w/ molded pins, loose ball, 9/16""
Components
  • Brakeset
    Front: Tektro, U-brake, single bushing, coil spring, 15mm offset arms
    Rear: Tektro, U-brake, die-cast, single bushing, coil spring, 15mm offset arms
  • Handlebar
    Specialized P.Series BMX bar, Hi-Ten steel, 710mm wide, 11-degree backsweep, 2-degree upsweep, 210mm rise, 22.2mm
  • Saddle
    P.Seat SL, 1pc. w/ co-molded alloy 25.4mm seatpost, padded
  • Seatpost
    Alloy, 25.4mm, integrated w/ saddle
  • Stem
    BMX stem, die-cast alloy, top load, 50mm, 22.2mm clamp

FAQ

Q: What size 2014 Specialized P.20 AM should I get?

After measuring your height, use the size chart below to find the typical Specialized P.20 AM size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm) Rider Height (in) Frame Size
148cm - 158cm 4'10" - 5'2" XS
158cm - 168cm 5'2" - 5'6" S
168cm - 178cm 5'6" - 5' 10" M
178cm - 185cm 5'10" - 6'1" L
185cm - 193cm 6'1" - 6'4" XL
193cm - 198cm 6'4" - 6'6" XXL
