Image of Specialized Enduro Expert EVO
2014

Specialized Enduro Expert EVO

Specialized Enduro 2014

Enduro

At a glance

The 2014 Specialized Enduro Expert EVO is an Enduro mountain bike. It sports 26" wheels, has Fox suspension and a SRAM drivetrain. The bike is part of Specialized's Enduro range of mountain bikes.

The 180mm-travel M5 aluminium Enduro FSR Expert EVO is an all- mountain machine catered to aggressive descending. Featuring patented Öhlins TTX22M Twin Tube shock, Fox 36 Van R and custom Avid Elixir 7 Trail hydraulic disc brakes the Enduro FSR Expert EVO strikes the perfect harmony between downhill and trail bikes.

Where To Buy

Reviews

Specifications

Frameset
  • Frame
    M5 aluminum, EVO geometry, tapered headtube, PF30 BB, ISCG '05 mount, internal Command Post IR routing, 142+ dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 180mm travel
  • Fork
    FOX 36 Van RC2, Kashima coating, coil spring, tapered alloy steerer, high/low speed comp and reb adj., 20mm thru-axle, 180mm travel
  • Shock
    Custom Ohlins TTX22M, coil over w/ piggy back, spherical bearing mount, high/low speed comp, reb adj., 8.75x2.5"", S: 76x434lb, M: 84x479lb, L: 92x525lb
Wheels
  • Hubs
    Front: Specialized Hi Lo disc, sealed cartridge bearings, 20mm thru-axle, 32h
    Rear: Custom DT Swiss, Star Ratchet, XX1 driver body, 142mm, 32h
  • Wheels
    Roval DH 26, alloy disc, 23mm internal width, 32h
  • Wheel Size
    26"
  • Spokes
    DT Industry Stainless, 3X front/rear 2.0mm
  • Tires
    Front: Specialized Butcher SX, 2Bliss Ready, 26x2.3"", foldable aramid bead, dual-compound, 60TPI
    Rear: Specialized Butcher SX, 2Bliss Ready, 26x2.3"", foldable aramid bead, dual-compound, 60TPI
Drivetrain
  • Chain
    SRAM X01, 11-speed, hollow plates/pins, PowerLink
  • Crank
    Custom SRAM carbon S-2200, 34T XX1 style single ring, PF30 spindle, removable spider, S: 170mm, Others: 175mm
  • Bottom Bracket
    SRAM PF30, OS press-in bearings, sealed cartridge
  • Rear Derailleur
    SRAM X01 Type 2, 11-speed, mid cage
  • Shifters
    SRAM X01, 11-speed, trigger
  • Cassette
    SRAM X01, 11-speed, 10-42
Components
  • Brakeset
    Front: Custom Avid Elixir 7 Trail, 4-piston caliper, steel backed metallic pad, 200mm rotor
    Rear: Custom Avid Elixir 7 Trail, 4-piston caliper, steel backed metallic pad, 180mm rotor
  • Handlebar
    Specialized Demo, low-rise, 7050 alloy, 780mm wide, 8-degree backsweep, 6-degree upsweep, 31.8mm
  • Saddle
    Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
  • Seatpost
    Specialized Command Post IR, 3-position, internally routed adjustable height w/ air spring, remote operated, single bolt head, 30.9mm, S:100mm, Others: 125mm travel
  • Stem
    Specialized P.Series MTB, forged alloy, 4-bolt, 40mm length, 31.8mm clamp

FAQ

Q: What size wheels does the 2014 Specialized Enduro Expert EVO have?

The 2014 Specialized Enduro Expert EVO has 26" wheels.

Q: What size 2014 Specialized Enduro Expert EVO should I get?

After measuring your height, use the size chart below to find the typical Specialized Enduro Expert EVO size for your height. Remember that these sizes are a general guide and bike sizes can vary between riders and bikes. The best way to find your size is to go for a test ride.

Rider Height (cm) Rider Height (in) Frame Size
148cm - 158cm 4'10" - 5'2" XS
158cm - 168cm 5'2" - 5'6" S
168cm - 178cm 5'6" - 5' 10" M
178cm - 185cm 5'10" - 6'1" L
185cm - 193cm 6'1" - 6'4" XL
193cm - 198cm 6'4" - 6'6" XXL
